RAYBESTOS 780223 Part Description
Manufacturer
Product Description
Raybestos Specialty - Truck Brake Rotor
Application Summary
2003 Dodge Ram 1500 Van Rear
Features & Benefits
- OE Fit, Form, and Function
- Our vehicle-specific design matches OE fit, form and function, providing ultimate strength and performance
- Cooling Vanes
- We dedicate time to match the cooling vanes on our Specialty rotors to OE designs, ensuring: Optimal cooling Reduced fade Less noise Increased pad life
- Coating
- All Specialty rotors are protected against the elements. All new Specialty rotors come fully coated with Grey Fusion 4.0® rated at 300 hrs. salt spray or a Black Fusion painted hat and edge for rust protection.
- All Specialty rotors are protected against the elements. All new Specialty rotors come fully coated with Grey Fusion 4.0(R) rated at 300 hrs. salt spray or a Black Fusion painted hat and edge for rust protection.
- SAE Standard for Tensile Strength
- Our rotors follow SAE standards for tensile strength, hardness, and iron grade, providing structural integrity and maximum service life
- Turned Finish
- A turned finish provides an excellent surface for the pads to engage with to ensure a smooth and effective stop right out of the box
RAYBESTOS 780223 Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 3.551 IN |
| Center Hole Diameter | 90.2 MM |
| Conventional Or Drum-In-Hat Type Rotor | Drum-In-Hat |
| Discard Thickness | 0.811 IN |
| Discard Thickness | 20.6 MM |
| Harmonize Code | 8708.30.5030 |
| Mounting Bolt Hole Circle Diameter | 5.5 IN |
| Mounting Bolt Hole Circle Diameter | 139.7 MM |
| Mounting Bolt Hole Diameter | 0.67 IN |
| Mounting Bolt Hole Diameter | 17 MM |
| Mounting Bolt Hole Quantity | 5 |
| Nominal Thickness | 0.866 IN |
| Nominal Thickness | 22 MM |
| Outside Diameter | 12.468 IN |
| Outside Diameter | 316.7 MM |
| Overall Height | 2.801 IN |
| Overall Height | 71.15 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Vented |
| Stud/Lug Hole Quantity | 5 |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00829352476406 |
RAYBESTOS 780223 Cross References
| Brand | Part Number |
|---|---|
| ASH23458, 829352476406 | |
| ADVANCE AUTO PARTS | YH200376 |
| AUTOZONE | 43178 |
| BENDIX | PRT6087 |
| BOSCH | 16010266 |
| BRAKEBEST | 16010266, 780223, 780223R, 780223RGS |
| BrakeBest | 780224RGS |
| CENTRIC | 120.67056, 120.67056CRY, 121.67056 |
| CHRYSLER | 52010362AA |
| Casting Numbers | 326308 |
| Centric Parts | 120.67056, 120.67056CRY, 121.67056 |
| DURA CORP | BR53016, BR900942 |
| DuraGo | 900942, BR53016, BR900942 |
| NEWTEK AUTOMOTIVE | 53016 |
| Newtek Automotive USA | 53016 |
| PROMAX | 14-53016 |
| PRONTO | BR900942 |
| Qualis | 43174 |
| UAP | 53016 |
| WAGNER | QC727 |
| WINHERE | 4420680 |
RAYBESTOS 780223 Fits Vehicles
- Dodge Ram 2500 Van (2003)
- Dodge Ram 1500 Van (2003)
