(888) 312-8812 Login SignupRAYBESTOS 780223R Raybestos R-Line Brake Rotor
No Stock Available
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
RAYBESTOS 780223R Part Description
Manufacturer
Product Description
Raybestos R-Line Brake Rotor
Application Summary
2003 Dodge Ram 1500 Van Rear
Features & Benefits
- OE Fit, Form, and Function
- Developed from OE samples and made with G3000-qualified material, ensuring OE fit, form and function for dependable braking.
- SAE Standard
- R-Line Rotors meet the SAE standard for tensile strength, providing structural integrity and a maximum service life.
- Low Initial Lateral Runout and Thickness Variation
- R-Line Rotors have a small parameter lateral runout and a thickness variation ensuring less pedal pulsation, less brake noise, and an extended pad life.
- Mill Balanced Edges
- R-Line Rotors are mill balanced and 100 percent validated. This helps minimize the thickness variation on the rotor and leads to minimized vibration and smoother stopping.
RAYBESTOS 780223R Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 3.551 IN |
| Center Hole Diameter | 90.2 MM |
| Conventional Or Drum-In-Hat Type Rotor | Drum-In-Hat |
| Discard Thickness | 0.811 IN |
| Discard Thickness | 20.6 MM |
| Harmonize Code | 8708.30.5030 |
| Mounting Bolt Hole Circle Diameter | 5.5 IN |
| Mounting Bolt Hole Circle Diameter | 139.7 MM |
| Mounting Bolt Hole Diameter | 0.67 IN |
| Mounting Bolt Hole Diameter | 17 MM |
| Mounting Bolt Hole Quantity | 5 |
| Nominal Thickness | 0.866 IN |
| Nominal Thickness | 22 MM |
| Outside Diameter | 12.468 IN |
| Outside Diameter | 316.7 MM |
| Overall Height | 2.801 IN |
| Overall Height | 71.15 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Vented |
| Stud/Lug Hole Quantity | 5 |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00829352597828 |
RAYBESTOS 780223R Cross References
| Brand | Part Number |
|---|---|
| BLR11368, 829352597828 | |
| ADVANCE AUTO PARTS | YH200376 |
| AUTOZONE | 43178 |
| BENDIX | PRT6087 |
| BOSCH | 16010266 |
| BRAKEBEST | 16010266, 780223, 780223R, 780223RGS |
| BrakeBest | 780224RGS |
| CENTRIC | 120.67056, 120.67056CRY, 121.67056 |
| CHRYSLER | 52010362AA |
| Casting Numbers | 326308 |
| Centric Parts | 120.67056, 120.67056CRY, 121.67056 |
| DURA CORP | BR53016, BR900942 |
| DuraGo | 900942, BR53016, BR900942 |
| MAGMA PRODUCTS | PMR145169 |
| NEWTEK AUTOMOTIVE | 53016 |
| Newtek Automotive USA | 53016 |
| PROMAX | 14-53016 |
| Qualis | 43174 |
| UAP | 53016 |
| WAGNER | QC727, BD126046 |
| WINHERE | 4420680 |
RAYBESTOS 780223R Fits Vehicles
- Dodge Ram 2500 Van (2003)
- Dodge Ram 1500 Van (2003)
