(888) 312-8812 Login SignupRAYBESTOS 96876R Raybestos R-Line Brake Rotor
No Stock Available
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
RAYBESTOS 96876R Part Description
Manufacturer
Product Description
Raybestos R-Line Brake Rotor
Application Summary
1995 Jaguar XJS Rear, 1984-1972 Jaguar XJ6 Rear, 1984-1982 Jaguar Vanden Plas Rear
Features & Benefits
- OE Fit, Form, and Function
- Developed from OE samples and made with G3000-qualified material, ensuring OE fit, form and function for dependable braking.
- SAE Standard
- R-Line Rotors meet the SAE standard for tensile strength, providing structural integrity and a maximum service life.
- Low Initial Lateral Runout and Thickness Variation
- R-Line Rotors have a small parameter lateral runout and a thickness variation ensuring less pedal pulsation, less brake noise, and an extended pad life.
- Mill Balanced Edges
- R-Line Rotors are mill balanced and 100 percent validated. This helps minimize the thickness variation on the rotor and leads to minimized vibration and smoother stopping.
RAYBESTOS 96876R Specifications
Product Attributes
| Center Hole Diameter | 2.75 IN |
| Center Hole Diameter | 69.85 MM |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Discard Thickness | 0.449 IN |
| Discard Thickness | 11.4 MM |
| Harmonize Code | 8708.30.5030 |
| Mounting Bolt Hole Circle Diameter | 3.75 IN |
| Mounting Bolt Hole Circle Diameter | 95.25 MM |
| Mounting Bolt Hole Diameter | 3.75 IN |
| Mounting Bolt Hole Diameter | 95.25 MM |
| Mounting Bolt Hole Quantity | 4 |
| Nominal Thickness | 0.5 IN |
| Nominal Thickness | 12.7 MM |
| Outside Diameter | 10.394 IN |
| Outside Diameter | 264 MM |
| Overall Height | 1.008 IN |
| Overall Height | 25.6 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Solid |
| Stud/Lug Hole Quantity | 4 |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00829352466902 |
RAYBESTOS 96876R Cross References
| Brand | Part Number |
|---|---|
| ASH12241, 829352466902 | |
| AUTOPART INTERNATIONAL | 78282 |
| AUTOZONE | 3478DG |
| BRAKEBEST | 96876, 96876R, 96876RGS |
| BREMBO | 25039 |
| CALIFORNIA DRUM & ROTOR | 125079 |
| CENTRIC | 120.20000, 125.20000, 121.20000 |
| Casting Numbers | 326159 |
| Centric Parts | 120.20000, 125.20000 |
| DURA CORP | BR3478 |
| EUROROTOR | JA152 |
| GREN | 450101 |
| JAGUAR | C43113, JLM730 |
| MIGHTY DISTRIBUTING SYSTEM | 3478 |
| NEWTEK AUTOMOTIVE | 3478 |
| Newtek Automotive USA | 3478 |
| PILENGA | 5822 |
| QUALIS | 3478 |
| STANDARD ROTORS AND DRUMS | 3478 |
| THE UNIVERSAL GROUP | 127780 |
| UAP | 3478 |
| Universal | 127780 |
| VIPAR - VEHICLE INDUSRTY PARTS & MANUFACTURING | X50533 |
RAYBESTOS 96876R Fits Vehicles
- Jaguar XJS (1995)
- Jaguar XJ6 (1972-1984)
- Jaguar Vanden Plas (1982-1984)
RAYBESTOS 96876R Customer Reviews
No reviews yet
Be the first to review this product!
RAYBESTOS 96876R Questions & Answers
No questions yet
Be the first to ask a question about this product!
