RAYBESTOS 980454R Part Description
Manufacturer
Product Description
Raybestos R-Line Brake Rotor
Application Summary
2012-2006 Mitsubishi Eclipse Rear, 2009-2007 Mitsubishi Galant Rear
Features & Benefits
- OE Fit, Form, and Function
- Developed from OE samples and made with G3000-qualified material, ensuring OE fit, form and function for dependable braking.
- SAE Standard
- R-Line Rotors meet the SAE standard for tensile strength, providing structural integrity and a maximum service life.
- Low Initial Lateral Runout and Thickness Variation
- R-Line Rotors have a small parameter lateral runout and a thickness variation ensuring less pedal pulsation, less brake noise, and an extended pad life.
- Mill Balanced Edges
- R-Line Rotors are mill balanced and 100 percent validated. This helps minimize the thickness variation on the rotor and leads to minimized vibration and smoother stopping.
RAYBESTOS 980454R Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 2.717 IN |
| Center Hole Diameter | 69 MM |
| Conventional Or Drum-In-Hat Type Rotor | Drum-In-Hat |
| Discard Thickness | 0.724 IN |
| Discard Thickness | 18.4 MM |
| Harmonize Code | 8708.30.5030 |
| Mounting Bolt Hole Circle Diameter | 4.5 IN |
| Mounting Bolt Hole Circle Diameter | 114.3 MM |
| Mounting Bolt Hole Diameter | 4.5 IN |
| Mounting Bolt Hole Diameter | 114.3 MM |
| Mounting Bolt Hole Quantity | 5 |
| Nominal Thickness | 0.787 IN |
| Nominal Thickness | 20 MM |
| Outside Diameter | 11.181 IN |
| Outside Diameter | 284 MM |
| Overall Height | 2.37 IN |
| Overall Height | 60.2 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Vented |
| Stud/Lug Hole Quantity | 5 |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00829352604472 |
RAYBESTOS 980454R Cross References
| Brand | Part Number |
|---|---|
| BRC255RM, 829352604472 | |
| ADVANCE AUTO PARTS | 200449, YH200449, YH200449C |
| AUTOPARTSOURCE | 475950 |
| AUTOZONE | 44640, 44640DG |
| BENDIX | PRT5878 |
| BRAKEBEST | 980454, 980454R, 980454RGS |
| CENTRIC | 120.46072, 121.46072, 126.46072CSL, 126.46072CSR, 126.46072SL, 126.46072SR, 127.46072L, 127.46072R, 128.46072L, 128.46072R, 320.46072 |
| Casting Numbers | 326344 |
| Centric Parts | 120.46072, 121.46072, 126.46072CSL, 126.46072CSR, 126.46072SL, 126.46072SR, 127.46072L, 127.46072R, 128.46072L, 128.46072R, 320.46072 |
| DURA CORP | BR31457, BR900592 |
| DuraGo | 900592, BR900592 |
| MAGMA PRODUCTS | PMR403015 |
| MITSUBISHI | 4615A057, 4615A111 |
| NEWTEK AUTOMOTIVE | 31457 |
| Newtek Automotive USA | 31457 |
| Omnicraft | QBRR652 |
| POWERSTOP | JBR1172EVC |
| PROMAX | 14-31457 |
| Qualis | 44640 |
| UAP | 31457 |
| WAGNER | F99060, BD180174 |
| WAGNER BRAKE | BD180174 |
| WINHERE | 6620822 |
RAYBESTOS 980454R Fits Vehicles
- Mitsubishi Galant (2007-2009)
- Mitsubishi Eclipse (2006-2012)
