(888) 312-8812 Login SignupRAYBESTOS 580171R Raybestos R-Line Brake Rotor
MSRP: $63.17
$4749
Save $15.68
Limited availability at this price!
In Stock
Get it by Thursday, Mar 5
RAYBESTOS 580171R Part Description
Manufacturer
Product Description
Raybestos R-Line Brake Rotor
Application Summary
2008-2004 Pontiac Grand Prix Rear, 2009-2005 Buick LaCrosse Rear, 2009-2005 Buick Allure Rear
Features & Benefits
- OE Fit, Form, and Function
- Developed from OE samples and made with G3000-qualified material, ensuring OE fit, form and function for dependable braking.
- SAE Standard
- R-Line Rotors meet the SAE standard for tensile strength, providing structural integrity and a maximum service life.
- Low Initial Lateral Runout and Thickness Variation
- R-Line Rotors have a small parameter lateral runout and a thickness variation ensuring less pedal pulsation, less brake noise, and an extended pad life.
- Mill Balanced Edges
- R-Line Rotors are mill balanced and 100 percent validated. This helps minimize the thickness variation on the rotor and leads to minimized vibration and smoother stopping.
RAYBESTOS 580171R Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 2.78 IN |
| Center Hole Diameter | 70.6 MM |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Directional or Non-Directional Brake Surface | Non-Directional |
| Discard Thickness | 0.492 IN |
| Discard Thickness | 12.5 MM |
| Harmonize Code | 8708.30.5030 |
| Material | Cast Iron |
| Mounting Bolt Hole Circle Diameter | 4.646 IN |
| Mounting Bolt Hole Circle Diameter | 118 MM |
| Mounting Bolt Hole Diameter | 0.636 IN |
| Mounting Bolt Hole Diameter | 16.15 MM |
| Mounting Bolt Hole Quantity | 5 |
| Nominal Thickness | 0.551 IN |
| Nominal Thickness | 14 MM |
| Outside Diameter | 10.63 IN |
| Outside Diameter | 270 MM |
| Overall Height | 1.445 IN |
| Overall Height | 36.7 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Solid |
| Stud/Lug Hole Quantity | 5 |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00829352364703 |
RAYBESTOS 580171R Cross References
RAYBESTOS 580171R Fits Vehicles
- Buick Allure (2005-2009)
- Buick LaCrosse (2005-2009)
- Pontiac Grand Prix (2004-2008)
