*Representative image - actual part not displayed
No Stock Available
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
CENTRIC 130.83022 Part Description
Manufacturer
Product Description
Centric Premium Brake Master Cylinder
Features & Benefits
- Match O.E. parts in quality; configuration and fitment. Complete with reservoirs; switches and floats. Original aluminum casting body design where applicable. Manufactured under the highest quality standards by OEM and OES manufacturers
CENTRIC 130.83022 Specifications
Product Attributes
| Push Rod: Length / Depth [cntrc] In | integrated |
| Boss, Nipple Or Port: Rear: #a [cntrc] | 9/16"-18 bbl |
| Weight [cntrc] Kgs | 2.8 |
| Secondary Outlet Flare Type [cntrc] | Bubble |
| Publication Bore [cntrc] | 13/16" |
| Boss, Nipple Or Port: Front, Left: #a [cntrc] | 1/2"-20 bbl |
| Weight [cntrc] Lbs | 6.15 |
| Primary Outlet Flare Type [cntrc] | Bubble |
| Product Grade [cntrc] | Premium |
| Dust Boot Included | Yes |
| Mounting Hardware Included | No |
| Mounting Hole Quantity | 2 |
| Master Cylinder Bore Diameter | 0.813 IN |
| Master Cylinder Bore Diameter | 20.638 MM |
| Brake Booster Included | No |
| Master Cylinder Cap Included | No |
| Master Cylinder Material | Cast Iron |
| Push Rod Included | Yes |
| Reservoir Included | No |
| Primary Outlet Thread Diameter | 0.5625 IN |
| Secondary Outlet Thread Diameter | 0.500 IN |
| Bleeder Hoses Included | No |
| Port Quantity | 2 |
| Mounting Bracket Included | No |
| 9275 | 20 IN |
| 9276 | 18 IN |
| Bore Type | Straight |
| Bore Size | 20.638 MM |
| Bore Size | 0.813 IN |
| Secondary Outlet Thread Size | 1/2"-20 |
| Primary Outlet Thread Size | 9/16"-18 |
| Primary Outlet Flare Type | Bubble |
| Secondary Outlet Flare Type | Bubble |
| Primary Bore Diameter | 20.638 MM |
| Primary Bore Diameter | 0.813 IN |
| Reservoir Style | Remote |
Additional Information
| Harmonized Tariff Code (HTS) | 8413919050 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | US |
| UPC | 00805890629207 |
CENTRIC 130.83022 Cross References
| Brand | Part Number |
|---|---|
| 2587200C91, 8C4Z2140C, 9C4Z2140A, 9C4Z2140C, S4684110050 | |
| MERITOR | R950056 |
| N/A | E135-88-027, S4684110050, 104485, L806CZ003AD, DC2C, DC2CAP, E13588027, 2587200C91, 9C4Z2140A, 9C4Z2140C, 8C4Z2140C |
CENTRIC 130.83022 Fits Vehicles
- International 4200 (2009-2010)
- International RXT (2006-2008)
- International MXT (2007-2009)
- International 4300LP (2009-2012)
- International 4300 (2009-2012)
- International 4400LP (2009-2012)
- International 4400 (2009-2012)
- International 4100 (2009-2012)
- International 3300 (2009-2011)
- International 3200 (2009-2011)
- IC Corporation CE Integrated (2010-2015)
- IC Corporation RE School Bus (2010-2015)
- IC Corporation RE Commercial (2010-2015)
- IC Corporation BE School Bus (2010-2012)
- IC Corporation HC Integrated Commercial (2010-2015)
- IC Corporation CE Commercial (2010-2015)
- IC Corporation CE School Bus (2010-2015)
- Ford F-750 (2004-2013, 2015)
- Ford F-650 (2004-2013, 2015)
