(888) 312-8812 Login SignupCENTRIC 130.63033 Centric Premium Brake Master Cylinder
*Representative image - actual part not displayed
No Stock Available
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
CENTRIC 130.63033 Part Description
Manufacturer
Product Description
Centric Premium Brake Master Cylinder
Features & Benefits
- Match O.E. parts in quality; configuration and fitment. Complete with reservoirs; switches and floats. Original aluminum casting body design where applicable. Manufactured under the highest quality standards by OEM and OES manufacturers
CENTRIC 130.63033 Specifications
Product Attributes
| Publication Bore [cntrc] | 15/16" |
| Boss, Nipple Or Port: Front, Left: #a [cntrc] | 9/16"-18 inv |
| Weight [cntrc] Lbs | 5.6 |
| Primary Outlet Flare Type [cntrc] | Inverted |
| Product Grade [cntrc] | Premium |
| Push Rod: Length / Depth [cntrc] In | integrated |
| Boss, Nipple Or Port: Rear: #a [cntrc] | 1/2"-20 inv |
| Weight [cntrc] Kgs | 2.55 |
| Secondary Outlet Flare Type [cntrc] | Inverted |
| Reservoir Material | Cast Iron |
| Dust Boot Included | Yes |
| Mounting Hardware Included | No |
| Mounting Hole Quantity | 2 |
| Master Cylinder Bore Diameter | 0.938 IN |
| Master Cylinder Bore Diameter | 23.813 MM |
| Brake Booster Included | No |
| Master Cylinder Cap Included | Yes |
| Master Cylinder Material | Cast Iron |
| Push Rod Included | Yes |
| Reservoir Included | Yes |
| Reservoir Type | Single |
| Primary Outlet Thread Diameter | 0.500 IN |
| Secondary Outlet Thread Diameter | 0.5625 IN |
| Bleeder Hoses Included | No |
| Port Quantity | 2 |
| Mounting Bracket Included | No |
| 9275 | 20 IN |
| 9276 | 20 IN |
| Bore Type | Straight |
| Bore Size | 23.813 MM |
| Bore Size | 0.938 IN |
| Secondary Outlet Thread Size | 9/16"-20 |
| Primary Outlet Thread Size | 1/2"-20 |
| Primary Outlet Flare Type | Inverted |
| Secondary Outlet Flare Type | Inverted |
| Primary Bore Diameter | 23.813 MM |
| Primary Bore Diameter | 0.938 IN |
| Reservoir Style | Integral |
Additional Information
| Harmonized Tariff Code (HTS) | 8413919050 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 00805890008781 |
CENTRIC 130.63033 Cross References
| Brand | Part Number |
|---|---|
| MC39448, F108161, MC108161 | |
| DORMAN | M39448 |
| N/A | MC108161, F108161, E135-68-038, ZY11955, 1028E, M900439, NM1955, CM1752, 65-M39448, 5364779, 5365053, J5364779, MC39448, 11955, 39448, 230263033, 2302-63033, 101955, M83033, E77090, 35542018, 18M239, 18030481, E13568038, M39448 |
| RAYBESTOS | MC39448 |
| WAGNER | MC108161 |
CENTRIC 130.63033 Fits Vehicles
- Jeep Scrambler (1983-1985)
- Jeep CJ7 (1983-1986)
- Jeep CJ5 (1983)
