CENTRIC 402.65001 Part Description
Manufacturer
Product Description
Centric Premium Hub and Bearing Assembly; With Integral ABS
Features & Benefits
- 100% O.E. Quality Components. Premium seals protect internal components. Exacting Fit and Function. Complete cataloging; featuring the latest applications and covering from 1940 to 2017
- Double Row Ball or Taper Roller Bearings include integral encoder for ABS and TCS where applicable
- Gen 1
- Gen 2
- Double Row Ball or Taper Roller Bearing Assemblies include one mounting flange - includes integral encoder for ABS, TCS where applicable
- Gen 3
- Double Row Ball or Taper Roller Bearing Assemblies include 2 mounting flanges - includes integral ABS sensor where applicable
CENTRIC 402.65001 Specifications
Product Attributes
| Thread Pitch To Wheel Mounting [cntrc] Mm | 1.500 |
| Mouting Thread Size [cntrc] Mm | 14.000 |
| Bolt Circle Diameter [cntrc] Mm | 170.000 |
| Mounting Hole Qty [cntrc] | 4 |
| Off-set [cntrc] Mm | 2.140 |
| Inner Mount Pilot [cntrc] In | 4.480 |
| Off-set [cntrc] In | 54.360 |
| Inner Mount Pilot [cntrc] Mm | 113.790 |
| Product Grade [cntrc] | Premium |
| Bolt Circle Diameter [cntrc] In | 6.693 |
| Notes [cntrc] | ABS Ring = 60 Teeth; Radial Design /¹ 4WD Hub Engage Ring Teeth / Inner Brg = SCE |
| Spline Quantity | 55 |
| Wheel Stud Size | 12.000 MM |
| Wheel Pilot Diameter | 124.710 MM |
| Wheel Pilot Diameter | 4.910 IN |
| Brake Pilot Diameter | 128.780 MM |
| Brake Pilot Diameter | 5.070 IN |
| Wheel Stud Quantity | 5 |
| Wheel Studs Included | Yes |
| Flange Diameter | 7.980 IN |
| Flange Diameter | 202.690 MM |
Additional Information
| Harmonized Tariff Code (HTS) | 8482105016 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | US |
| UPC | 00805890564300 |
CENTRIC 402.65001 Cross References
| Brand | Part Number |
|---|---|
| BCA | WE60751, WE60751HW |
| GMB | 7250088 |
| MEVOTECH | H515020 |
| N/A | H515020, 515020, 53036720, 145097, BR930420, FW720, WE60751, F81Z 1104BG, F81Z 1104BH, F81Z1104BG, F81Z1104BH |
| NTN | WE60751 |
| TIMKEN | 515020 |
CENTRIC 402.65001 Fits Vehicles
- Ford F-350 Super Duty (1999-2002)
- Ford F-250 Super Duty (1999-2002)
- Ford Excursion (2000-2002)
