ICON 48602 Part Description
Manufacturer
Product Description
21-23 BRONCO HOSS 2.0 PKG 2.5 FRONT EXP COILOVER
Features & Benefits
- Vehicle specific design for 2021-2023 Ford Bronco with HOSS. 2.0 Suspension Package
- Vehicle specific tuned for superior shock damping and control
- 2.5 Aluminum Series Shock with Internal Reservoir
- Adjustable ride heights from 0-2” of front lift over stock with the use of snap ring
- Utilizes factory coil and coil hardware
- Inverted shaft up design featuring 7/8” diameter, induction hardened, chrome plated shaft
- One-piece, impact extruded, hard anodized aluminum cylinder offer excellent corrosion resistance and consistent finish
- CNC machined 6061 aluminum components with a black anodized finish
- PTFE lined spherical bearing for extended longevity and minimal deflection
- High strength alloy CNC machined lower bar pin
- 100% Bolt-on - no cutting or welding necessary for installation
- Fully rebuildable and re-tunable
OEM Wheels & Tires Fitment: Yes
21-UP BRONCO HOSS 2.0 PKG 2.5 FRONT
ICON 48602 Specifications
Product Attributes
| Aap_uda_12 | EA |
| Aap_uda_22 | 1 |
| Aap_uda_4 | 55 |
| Active or Passive Suspension | Passive |
| Add-on Part | 48400DJ - 21-23 BRONCO TUBULAR UCA DJ PRO KIT |
| Adjustable Compression | No |
| Adjustable Damping | NO |
| Adjustable Height | Yes |
| Adjustable Rebound | No |
| Body Diameter | 2.5 in |
| Boot Included | No |
| California Prop 65 Warning | Yes |
| Coil Over Springs Included | No |
| Cylinder Color | Gray |
| Cylinder Finish | Hard Anodized |
| Cylinder Material | Aluminum |
| Damping Type | Oil |
| Dust Shield | No |
| Dust Shield Included | No |
| Gas Charged | Yes |
| Grade Type | Performance |
| Internal Construction Type | Single Tube |
| Lower Mount Type | BAR PIN |
| Material | Aluminum |
| Maximum Lift | 2 IN |
| Minimum Lift | 0 IN |
| OEM Wheels & Tires Fitment | Yes |
| Recommended Aftermarket Tires | (With Sasquatch Package): 35" x 12.50" (37" tire packages may require fender trimming and modifications) |
| Recommended Aftermarket Wheels | (With Sasquatch Package): ICON Alloys - 18x9" w/ 5" Backspace / 0mm Offset |
| Remote Reservoir | NO |
| Reservoir Style | Internal |
| Self-Leveling | No |
| Service Parts | 252010 - 2.5 IFP REBUILD KIT |
| Shaft Diameter | 0.875 IN |
| Shock Absorber Body End Measuring Point | Top of Upper Mount Plate |
| Shock Absorber Rod End Measuring Point | Flat on Bar Pin |
| Spring Color | Black |
| Spring Rate Type | Linear |
| Title | ICON 2021-2023 Ford Bronco, Hoss 2.0 Pkg, Front, 0-2” Lift, 2.5 EXP Series Coilover |
| Upper Mount Type | Mounting Plate |
| Valving Type | Digressive |
Additional Information
| Warranty Time | 1 |
| Warranty Time UOM | YR |
| Country of Origin (Primary) | US |
| Harmonized Tariff Code (Schedule B) | 8708807000 |
| NAFTA Preference Criterion Code | C |
| UPC | 00840103414300 |
ICON 48602 Cross References
| Brand | Part Number |
|---|---|
| BILSTEIN | 24-318594 |
ICON 48602 Fits Vehicles
- Ford Bronco (2021-2024)
