(888) 312-8812 Login SignupCENTRIC 125.20016 Centric Premium High Carbon Alloy Brake Rotor
Tap to view 1 more
MSRP: $104.73
$3449
Save $70.24
Limited availability at this price!
In Stock
Get it by Thursday, Mar 12
CENTRIC 125.20016 Part Description
Manufacturer
Product Description
Centric Premium High Carbon Alloy Brake Rotor
Features & Benefits
- Centric Premium Rotor with advanced metallurgy that greatly reduces pad squeal. Especially effective with higher friction; European style brake pad compounds. Added Molybdenum and Chromium to resist rotor cracking
- Painted hat and outer edge for corrosion resistance
- Painted Hat and Outer Edge
- Optimal Surface Finish
- Optimal surface finish for consistent stopping feel from the first stop
- Advanced Metallurgy
- Advanced metallurgy for optimal heat transfer and structural strength
- OE Vane Design and Plate Thickness
- OE vane design and plate thickness for heat capacity and strength
- Low Initial Lateral Run-Out
- Low initial lateral run-out and disc thickness variation for smooth, vibration free stopping
- Precision Balance
- Precision balance for vibration free performance
CENTRIC 125.20016 Specifications
Product Attributes
| Weight [cntrc] Lbs | 32.890 |
| Max Pb Drum Dia [cntrc] In | 0.244 |
| Disc Mounting [cntrc] | Floating |
| Max Pb Drum Dia [cntrc] Mm | 6.200 |
| Weight [cntrc] Kgs | 14.950 |
| Product Grade [cntrc] | Premium |
| Misc Holes [cntrc] | 5 |
| Vane Style [cntrc] | Straight |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Discard Thickness | 22.000 MM |
| Discard Thickness | 0.866 IN |
| Nominal Thickness | 0.945 IN |
| Nominal Thickness | 24.000 MM |
| Hat Finish | Painted |
| Overall Height | 47.100 MM |
| Overall Height | 1.854 IN |
| Outside Diameter | 300.000 MM |
| Outside Diameter | 11.811 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Nominal Drum Diameter | 154.900 MM |
| Nominal Drum Diameter | 6.098 IN |
| Bearings Included | No |
| Center Hole Diameter | 63.500 MM |
| Center Hole Diameter | 2.500 IN |
| Mounting Bolt Hole Circle Diameter | 4.252 IN |
| Mounting Bolt Hole Circle Diameter | 108.000 MM |
| Stud/Lug Hole Quantity | 5 |
| Stud/Lug Hole Diameter | 13.750 MM |
| Stud/Lug Hole Diameter | 0.541 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00805890250951 |
CENTRIC 125.20016 Cross References
| Brand | Part Number |
|---|---|
| N/A | BD126250, 424161, 6433110, 1F4D, 1S7W1125AC/B, 34251, YH145572, A5971, 25681, 09866510, 34251G, C2S35270, C2S42667, C2S4566, C2S49729, 4181042, 1376118, 1388257, 1465618, 1506298, 4110587, 1S7W1125AB, 1S7W1125AC, 1S7W1125B3B, 1S7W1125B3D, 1S7W1125CA, 1S7W1125CB, 4097477, 4179398, 1321488, 4097478, 980234P, 86567, DDF1125, 90020012 |
| RAYBESTOS | 980234, 980234FZN, 980234R |
| Raybestos Brakes | 980234FZN, 980234R, 980234 |
| WAGNER | BD125642E, BD126250 |
CENTRIC 125.20016 Fits Vehicles
- Ford Mondeo (2001-2007)
- Jaguar X-Type (2002-2008)
