CENTRIC 123.67031 Part Description
Manufacturer
Product Description
C-Tek Standard Brake Drum
Features & Benefits
- Non-Directional Finishes. Machined non-friction surfaces. Widest application coverage in the aftermarket
- For best operation and ultimate strength
- OE-Matched Fit, Form, and Function
- 100% Mill Balanced
- For vibration free performance
- Meets SAE Standard for Tensile Strength
- For maximum service life and structural integrity
CENTRIC 123.67031 Specifications
Product Attributes
| Weight [cntrc] Kgs | 17.045 |
| Weight [cntrc] Lbs | 37.500 |
| Mounting Type [cntrc] | Floating |
| Bolt Circle Diameter [cntrc] Mm | 165.100 |
| Bolt Circle Diameter [cntrc] In | 6.500 |
| Hub Hole / Register [cntrc] Mm | 122.936 |
| Hub Hole / Register [cntrc] In | 4.840 |
| Height [cntrc] Mm | 129.540 |
| Height [cntrc] In | 5.100 |
| Friction Surface Width [cntrc] Mm | 88.900 |
| Friction Surface Width [cntrc] In | 3.500 |
| Product Grade [cntrc] | Standard |
| Maximum Brake Diameter (Discard) | 307.000 MM |
| Maximum Brake Diameter (Discard) | 12.087 IN |
| Bolt Hole Quantity | 8 |
| Outside Diameter | 357.378 MM |
| Outside Diameter | 14.070 IN |
| Outer Cooling Fins | Yes |
| Mounting Hole Diameter | 17.020 MM |
| Mounting Hole Diameter | 0.670 IN |
| Nominal Drum Diameter | 304.800 MM |
| Nominal Drum Diameter | 12.000 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 00805890140771 |
CENTRIC 123.67031 Cross References
| Brand | Part Number |
|---|---|
| 109636 | |
| MAGMA PRODUCTS | PMU14089 |
| N/A | E127-72-036, E128-72-036, 80024, BD80024, 123.67031, 80024G, 52008591, 203260, 140686, PDR0686, 6401712, 440-1712, AD8731, AD8731E, E11104, E12772036, E12872036, 87636, 2339207, BD1655, 109636, 9636, 9636R, 9636DGS, 68465, 36540049 |
| PRONTO | BD80024 |
| RAYBESTOS | 9636, 9636R |
| WAGNER | BD125465 |
CENTRIC 123.67031 Fits Vehicles
- Dodge B350 (1994)
- Dodge B2500 (1995-1997)
- Dodge B3500 (1995-1997)
- Dodge B250 (1994)
