CENTRIC 122.67031 Part Description
Manufacturer
Features & Benefits
- For best operation and ultimate strength
- OE-Matched Fit, Form, and Function
- 100% Mill Balanced
- For vibration free performance
- Black Painted Exterior
- For corrosion resistance
CENTRIC 122.67031 Specifications
Product Attributes
| Weight [cntrc] Kgs | 17.045 |
| Weight [cntrc] Lbs | 37.500 |
| Mounting Type [cntrc] | Floating |
| Bolt Circle Diameter [cntrc] Mm | 165.100 |
| Bolt Circle Diameter [cntrc] In | 6.500 |
| Hub Hole / Register [cntrc] Mm | 122.936 |
| Hub Hole / Register [cntrc] In | 4.840 |
| Height [cntrc] Mm | 129.540 |
| Height [cntrc] In | 5.100 |
| Friction Surface Width [cntrc] Mm | 88.900 |
| Friction Surface Width [cntrc] In | 3.500 |
| Product Grade [cntrc] | Premium |
| Maximum Brake Diameter (Discard) | 307.000 MM |
| Maximum Brake Diameter (Discard) | 12.087 IN |
| Bolt Hole Quantity | 8 |
| Outside Diameter | 433.578 MM |
| Outside Diameter | 17.070 IN |
| Outer Cooling Fins | Yes |
| Mounting Hole Diameter | 17.020 MM |
| Mounting Hole Diameter | 0.670 IN |
| Nominal Drum Diameter | 304.800 MM |
| Nominal Drum Diameter | 12.000 IN |
