CENTRIC 122.65042 Part Description
Manufacturer
Features & Benefits
- For best operation and ultimate strength
- OE-Matched Fit, Form, and Function
- 100% Mill Balanced
- For vibration free performance
- Black Painted Exterior
- For corrosion resistance
CENTRIC 122.65042 Specifications
Product Attributes
| Weight [cntrc] Kgs | 8.409 |
| Weight [cntrc] Lbs | 18.500 |
| Mounting Type [cntrc] | Floating |
| Bolt Circle Diameter [cntrc] Mm | 135.000 |
| Bolt Circle Diameter [cntrc] In | 5.310 |
| Hub Hole / Register [cntrc] Mm | 87.376 |
| Hub Hole / Register [cntrc] In | 3.440 |
| Height [cntrc] Mm | 92.964 |
| Height [cntrc] In | 3.660 |
| Friction Surface Width [cntrc] Mm | 71.120 |
| Friction Surface Width [cntrc] In | 2.800 |
| Product Grade [cntrc] | Premium |
| Maximum Brake Diameter (Discard) | 282.400 MM |
| Maximum Brake Diameter (Discard) | 11.118 IN |
| Bolt Hole Quantity | 5 |
| Outside Diameter | 331.978 MM |
| Outside Diameter | 13.070 IN |
| Outer Cooling Fins | No |
| Mounting Hole Diameter | 16.000 MM |
| Mounting Hole Diameter | 0.630 IN |
| Nominal Drum Diameter | 280.700 MM |
| Nominal Drum Diameter | 11.050 IN |
