(888) 312-8812 Login SignupCENTRIC 122.63019 Premium Brake Drum
Tap to view 1 more
No Stock Available
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
CENTRIC 122.63019 Part Description
Manufacturer
Features & Benefits
- For best operation and ultimate strength
- OE-Matched Fit, Form, and Function
- 100% Mill Balanced
- For vibration free performance
- Black Painted Exterior
- For corrosion resistance
CENTRIC 122.63019 Specifications
Product Attributes
| Weight [cntrc] Kgs | 8.636 |
| Weight [cntrc] Lbs | 19.000 |
| Mounting Type [cntrc] | Floating |
| Bolt Circle Diameter [cntrc] Mm | 114.300 |
| Bolt Circle Diameter [cntrc] In | 4.500 |
| Hub Hole / Register [cntrc] Mm | 72.136 |
| Hub Hole / Register [cntrc] In | 2.840 |
| Height [cntrc] Mm | 111.506 |
| Height [cntrc] In | 4.390 |
| Friction Surface Width [cntrc] Mm | 73.914 |
| Friction Surface Width [cntrc] In | 2.910 |
| Product Grade [cntrc] | Premium |
| Maximum Brake Diameter (Discard) | 256.300 MM |
| Maximum Brake Diameter (Discard) | 10.090 IN |
| Bolt Hole Quantity | 5 |
| Outside Diameter | 319.532 MM |
| Outside Diameter | 12.580 IN |
| Outer Cooling Fins | Yes |
| Mounting Hole Diameter | 16.510 MM |
| Mounting Hole Diameter | 0.650 IN |
| Nominal Drum Diameter | 254.000 MM |
| Nominal Drum Diameter | 10.000 IN |
