(888) 312-8812 Login SignupCENTRIC 122.61016 Prm Brake Drum
Tap to view 1 more
No Stock Available
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
CENTRIC 122.61016 Part Description
Manufacturer
Features & Benefits
- For best operation and ultimate strength
- OE-Matched Fit, Form, and Function
- 100% Mill Balanced
- For vibration free performance
- Black Painted Exterior
- For corrosion resistance
CENTRIC 122.61016 Specifications
Product Attributes
| Weight [cntrc] Kgs | 5.068 |
| Weight [cntrc] Lbs | 11.150 |
| Mounting Type [cntrc] | Floating |
| Bolt Circle Diameter [cntrc] Mm | 114.300 |
| Bolt Circle Diameter [cntrc] In | 4.500 |
| Hub Hole / Register [cntrc] Mm | 70.612 |
| Hub Hole / Register [cntrc] In | 2.780 |
| Height [cntrc] Mm | 84.582 |
| Height [cntrc] In | 3.330 |
| Friction Surface Width [cntrc] Mm | 51.816 |
| Friction Surface Width [cntrc] In | 2.040 |
| Product Grade [cntrc] | Premium |
| Maximum Brake Diameter (Discard) | 256.300 MM |
| Maximum Brake Diameter (Discard) | 10.090 IN |
| Bolt Hole Quantity | 5 |
| Outside Diameter | 295.910 MM |
| Outside Diameter | 11.650 IN |
| Outer Cooling Fins | No |
| Mounting Hole Diameter | 14.224 MM |
| Mounting Hole Diameter | 0.560 IN |
| Nominal Drum Diameter | 254.000 MM |
| Nominal Drum Diameter | 10.000 IN |
