CENTRIC 122.44023 Part Description
Manufacturer
Features & Benefits
- For best operation and ultimate strength
- OE-Matched Fit, Form, and Function
- 100% Mill Balanced
- For vibration free performance
- Black Painted Exterior
- For corrosion resistance
CENTRIC 122.44023 Specifications
Product Attributes
| Misc Holes [cntrc] | 4 |
| Weight [cntrc] Kgs | 7.614 |
| Weight [cntrc] Lbs | 16.750 |
| Mounting Type [cntrc] | Floating |
| Bolt Circle Diameter [cntrc] Mm | 154.000 |
| Bolt Circle Diameter [cntrc] In | 6.063 |
| Hub Hole / Register [cntrc] Mm | 114.000 |
| Hub Hole / Register [cntrc] In | 4.488 |
| Height [cntrc] Mm | 86.500 |
| Height [cntrc] In | 3.406 |
| Friction Surface Width [cntrc] Mm | 76.000 |
| Friction Surface Width [cntrc] In | 2.992 |
| Product Grade [cntrc] | Premium |
| Maximum Brake Diameter (Discard) | 256.000 MM |
| Maximum Brake Diameter (Discard) | 10.079 IN |
| Bolt Hole Quantity | 6 |
| Outside Diameter | 302.000 MM |
| Outside Diameter | 11.890 IN |
| Outer Cooling Fins | No |
| Mounting Hole Diameter | 10.500 MM |
| Mounting Hole Diameter | 0.413 IN |
| Nominal Drum Diameter | 254.000 MM |
| Nominal Drum Diameter | 10.000 IN |
