SPICER 5-7166X Part Description
Manufacturer
Product Description
Axle Shaft Universal Joint; Non-Greaseable; 1350WJ Series
Features & Benefits
- Journal cross is engineered with a solid cold-formed body to ensure better wear and overall strength.
- Bearing cups are heat treated for strength; precision-ground and case-hardened for durability.
- Multi-lip seal keeps grease in and contaminants out, and gets maximum retention in a wider range of environments.
- Thrust washers eliminate metal-to-metal contact, prevent wear and lower the overall operating temperature.
Universal Joint
SPICER 5-7166X Specifications
Product Attributes
| Distance Btw Snap Ring Grooves (ISR) (2) | 2.406 |
| Material | Steel |
| Bearing Cap Diameter (1) | 1.188 IN |
| OEM Mfg | Spicer |
| OEM Series | 1350WJ |
| Type | ISR Style |
| Bearing Cap Diameter (2) | 1.188 IN |
| Bearing Cap Type | Round with ISR Groove |
| Snap Ring Included | Yes |
| Snap Ring Type | Internal |
| Grease Zerk Included | Not Required |
| Pre Greased | Yes |
| Greaseable | No |
| Bearing Cap Diameter A (mm) | 30.175 MM |
| Bearing Cap Diameter B (mm) | 30.175 MM |
| Bearing Cap Type A | ISR |
| Bearing Cap Type B | ISR |
| Hardware Included | No |
| Length A (In) | 2.406 IN |
| Length A (mm) | 61.100 MM |
| Length B (In) | 2.406 IN |
| Length B (mm) | 61.112 MM |
| Mounting Hardware Included | No |
| Distance Btw Snap Ring Grooves | 2.406 |
Additional Information
| Country of Origin (Primary) | US |
| Harmonized Tariff Code (HTS) | 8708996810 |
| UPC | 00023913126384 |
| VMRS Code | 024002046 |
SPICER 5-7166X Cross References
| Brand | Part Number |
|---|---|
| Chrysler | 6801 7182AA, 68017182AA, 6814 5053AA, 68145053AA |
| DANA | 25-7166X, SPL30-7166XC |
| Dana Commercial Vehicle Service Parts | 5004891, 5017166, 5-17166X |
| GMB | 210-0057 |
| MOOG Chassis Products | 489, 491 |
| MasterPro | 489 |
| NEAPCO | 2-0057 |
| Navistar | DS57166X |
| Neapco OE Series | 2-0057 |
| Precision | 489 |
| SKF | 2-0057 |
