(888) 312-8812 Login SignupSPICER 5-793X Universal Joint
Tap to view 1 more
$5449
Limited availability at this price!
In Stock
Get it by Thursday, Mar 19
SPICER 5-793X Part Description
Manufacturer
Product Description
Universal Joint; Non-Greaseable
Features & Benefits
- Kit includes new self locking bearing plate bolts and new strap kits.
- Journal cross is engineered with a solid cold-formed body to ensure better wear and overall strength.
- Multi-lip seal keeps grease in and contaminants out, and gets maximum retention in a wider range of environments.
- Thrust washers eliminate metal-to-metal contact, prevent wear and lower the overall operating temperature.
Universal Joint
SPICER 5-793X Specifications
Product Attributes
| Material | Steel |
| Bearing Cap Diameter (1) | 1.125 IN |
| OEM Mfg | Spicer |
| OEM Series | S44-3R/1330 |
| Type | ISR/OSR Style |
| Bearing Cap Diameter (2) | 1.062 IN |
| Converts This Series | S44/3R |
| To This Series | 1330 |
| Bearing Cap Type | Round/Round with ISR Groove |
| Snap Ring Included | Yes |
| Snap Ring Type | Internal/External |
| Grease Zerk Included | Not Required |
| Pre Greased | Yes |
| Greaseable | No |
| Bearing Cap Diameter A (mm) | 28.575 MM |
| Bearing Cap Diameter B (mm) | 26.975 MM |
| Bearing Cap Type A | ISR |
| Bearing Cap Type B | OSR |
| Hardware Included | No |
| Length A (In) | 2.556 IN |
| Length A (mm) | 64.922 MM |
| Length B (In) | 3.625 IN |
| Length B (mm) | 92.075 MM |
| Mounting Hardware Included | No |
| Sr(2)brng Cap To Brng Cap(osr) | 3.625 |
| Distance Btw Snap Ring Grooves | 2.556 |
Additional Information
| Country of Origin (Primary) | US |
| Harmonized Tariff Code (HTS) | 8708996890 |
| UPC | 00023913121198 |
| VMRS Code | 024002046 |
SPICER 5-793X Cross References
| Brand | Part Number |
|---|---|
| ACDelco | 45U0113, 45U0166, 45U0404 |
| Chrysler | 5093820AA |
| Daimler Truck North America | SP 5 793X, SP 5 793XHP |
| Dana Commercial Vehicle Service Parts | 5003097, 5-619X, 5-7436X, 5-793XSB, 5-794X |
| Freightliner | SP 5 793X, SP 5 793XHP |
| GMB | 2400231 |
| International Harvester (IHC) | D5793X, DSPL254X, E5793X, 5793X |
| Isuzu | 8-89040-245-0 |
| MOOG | 355 |
| MOOG Chassis Products | 290, 355, 355C |
| MasterPro | 290, 355, 355C |
| McNeilus | 1324128 |
| NEAPCO | 2-1569P, 2-1569G |
| Navistar | 5621X, 5793X, D5793X, DS5793X, DSPL254X, E5621X, E5744X, E5745X, E5793X, E5794X, ESPL254X, ESPL255X, SPL254X |
| Neapco OE Series | 2-0621, 2-0793, 2-1569, 2-1569G, 2-1569P |
| Peterbilt | 1324128 |
| Precision | 290, 355, 355C |
| SKF | 2-0621, 2-0793, 2-1569, 2-1569G, UJ290, UJ355 |
| Spicer | 5-212X |
| Volvo | SP 5793X |
