(888) 312-8812 Login SignupCENTRIC 120.45079 Centric Premium Brake Rotor
Tap to view 4 more
No Stock Available
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
CENTRIC 120.45079 Part Description
Manufacturer
Product Description
Centric Premium Brake Rotor
Features & Benefits
- Symmetric vane; split-core castings for uniform heat distribution. Black E-Coat anti-corrosive coating protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life
- Painted hat and outer edge for corrosion resistance
- Symmetric vane; split-core castings for uniform heat distribution. Anti-corrosive paint protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life.
- Painted Hat and Outer Edge
- Optimal Surface Finish
- Optimal surface finish for consistent stopping feel from the first stop
- Advanced Metallurgy
- Advanced metallurgy for optimal heat transfer and structural strength
- OE Vane Design and Plate Thickness
- OE vane design and plate thickness for heat capacity and strength
- Low Initial Lateral Run-Out
- Low initial lateral run-out and disc thickness variation for smooth, vibration free stopping
- Precision Balance
- Precision balance for vibration free performance
CENTRIC 120.45079 Specifications
Product Attributes
| Vane Style [cntrc] | Straight |
| Misc Holes [cntrc] | 4 |
| Weight [cntrc] Lbs | 18.100 |
| Product Grade [cntrc] | Premium |
| Disc Mounting [cntrc] | Floating |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Weight [cntrc] Kgs | 8.230 |
| Discard Thickness | 0.630 IN |
| Discard Thickness | 16.000 MM |
| Nominal Thickness | 0.709 IN |
| Nominal Thickness | 18.000 MM |
| Hat Finish | Painted |
| Overall Height | 2.205 IN |
| Overall Height | 56.000 MM |
| Outside Diameter | 324.000 MM |
| Outside Diameter | 12.756 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Bearings Included | No |
| Center Hole Diameter | 2.835 IN |
| Center Hole Diameter | 72.000 MM |
| Mounting Bolt Hole Circle Diameter | 114.300 MM |
| Mounting Bolt Hole Circle Diameter | 4.500 IN |
| Stud/Lug Hole Quantity | 5 |
| Stud/Lug Hole Diameter | 13.000 MM |
| Stud/Lug Hole Diameter | 0.512 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00805890413110 |
CENTRIC 120.45079 Cross References
| Brand | Part Number |
|---|---|
| 980579, BD126498 | |
| ADVICS | E6R121U |
| N/A | BD126498, E125-50-084, 1407-77103, 44604, YH200483, 31480, 44604G, TD1126251, L23226251, L23226251B, L23226251C, 850002, 90080068, E12550084 |
| NEOTEK | 106642GF |
| Neotek Premium Drums and Rotors | 106642GF |
| PRONTO | BR90035602 |
| RAYBESTOS | 980579, 980579FZN, 980579R, 980579R2 |
| Raybestos Brakes | 980579, 980579FZN, 980579R |
| WAGNER | BD126498E, BD126498 |
CENTRIC 120.45079 Fits Vehicles
- Mazda CX-9 (2007-2015)
CENTRIC 120.45079 Customer Reviews
No reviews yet
Be the first to review this product!
CENTRIC 120.45079 Questions & Answers
No questions yet
Be the first to ask a question about this product!
