(888) 312-8812 Login SignupCENTRIC 120.34086 Premium Brake Rotor
Tap to view 1 more
No Stock Available
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
CENTRIC 120.34086 Part Description
Manufacturer
Features & Benefits
- Painted hat and outer edge for corrosion resistance
- Painted Hat and Outer Edge
- Optimal Surface Finish
- Optimal surface finish for consistent stopping feel from the first stop
- Advanced Metallurgy
- Advanced metallurgy for optimal heat transfer and structural strength
- OE Vane Design and Plate Thickness
- OE vane design and plate thickness for heat capacity and strength
- Low Initial Lateral Run-Out
- Low initial lateral run-out and disc thickness variation for smooth, vibration free stopping
- Precision Balance
- Precision balance for vibration free performance
CENTRIC 120.34086 Specifications
Product Attributes
| Misc Holes [cntrc] | 1 |
| Product Grade [cntrc] | Premium |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Vane Style [cntrc] | Straight |
| Weight [cntrc] Lbs | 21.850 |
| Disc Mounting [cntrc] | Floating / DIH |
| Weight [cntrc] Kgs | 9.930 |
| Discard Thickness | 0.882 IN |
| Discard Thickness | 22.400 MM |
| Nominal Thickness | 23.800 MM |
| Nominal Thickness | 0.937 IN |
| Hat Finish | Painted |
| Overall Height | 2.913 IN |
| Overall Height | 74.000 MM |
| Outside Diameter | 344.600 MM |
| Outside Diameter | 13.567 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Nominal Drum Diameter | 185.000 MM |
| Nominal Drum Diameter | 7.283 IN |
| Bearings Included | No |
| Center Hole Diameter | 3.106 IN |
| Center Hole Diameter | 78.900 MM |
| Mounting Bolt Hole Circle Diameter | 4.724 IN |
| Mounting Bolt Hole Circle Diameter | 120.000 MM |
| Stud/Lug Hole Quantity | 5 |
| Stud/Lug Hole Diameter | 0.657 IN |
| Stud/Lug Hole Diameter | 16.700 MM |
CENTRIC 120.34086 Cross References
| Brand | Part Number |
|---|---|
| 829352692097 | |
| RAYBESTOS | 980649, 980649R |
| WAGNER | BD180118 |
CENTRIC 120.34086 Fits Vehicles
- BMW 750i (2006-2008)
- BMW 750Li (2006-2008)
- BMW 760i (2005-2006)
- BMW 760Li (2005-2008)
