(888) 312-8812 Login SignupCENTRIC 120.33098 Premium Brake Rotor
Tap to view 1 more
No Stock Available
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
CENTRIC 120.33098 Part Description
Manufacturer
Features & Benefits
- Painted hat and outer edge for corrosion resistance
- Painted Hat and Outer Edge
- Optimal Surface Finish
- Optimal surface finish for consistent stopping feel from the first stop
- Advanced Metallurgy
- Advanced metallurgy for optimal heat transfer and structural strength
- OE Vane Design and Plate Thickness
- OE vane design and plate thickness for heat capacity and strength
- Low Initial Lateral Run-Out
- Low initial lateral run-out and disc thickness variation for smooth, vibration free stopping
- Precision Balance
- Precision balance for vibration free performance
CENTRIC 120.33098 Specifications
Product Attributes
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Weight [cntrc] Kgs | 8.550 |
| Vane Style [cntrc] | Straight |
| Hat Id [cntrc] In | 5.693 |
| Product Grade [cntrc] | Premium |
| Disc Mounting [cntrc] | Floating |
| Hat Id [cntrc] Mm | 144.600 |
| Misc Holes [cntrc] | 5 |
| Weight [cntrc] Lbs | 18.800 |
| Discard Thickness | 0.866 IN |
| Discard Thickness | 22.000 MM |
| Nominal Thickness | 0.976 IN |
| Nominal Thickness | 24.800 MM |
| Hat Finish | Painted |
| Overall Height | 49.300 MM |
| Overall Height | 1.941 IN |
| Outside Diameter | 12.283 IN |
| Outside Diameter | 312.000 MM |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Bearings Included | No |
| Center Hole Diameter | 2.559 IN |
| Center Hole Diameter | 65.000 MM |
| Mounting Bolt Hole Circle Diameter | 4.413 IN |
| Mounting Bolt Hole Circle Diameter | 112.100 MM |
| Stud/Lug Hole Quantity | 5 |
| Stud/Lug Hole Diameter | 0.606 IN |
| Stud/Lug Hole Diameter | 15.400 MM |
Additional Information
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00805890581321 |
CENTRIC 120.33098 Cross References
CENTRIC 120.33098 Fits Vehicles
- Volkswagen Jetta (2022-2023)
- Volkswagen Taos (2021)
- Audi TT Quattro (2018-2023)
