(888) 312-8812 Login SignupCENTRIC 120.33003 Premium Brake Rotor
Tap to view 1 more
No Stock Available
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
CENTRIC 120.33003 Part Description
Manufacturer
Features & Benefits
- Painted hat and outer edge for corrosion resistance
- Painted Hat and Outer Edge
- Optimal Surface Finish
- Optimal surface finish for consistent stopping feel from the first stop
- Advanced Metallurgy
- Advanced metallurgy for optimal heat transfer and structural strength
- OE Vane Design and Plate Thickness
- OE vane design and plate thickness for heat capacity and strength
- Low Initial Lateral Run-Out
- Low initial lateral run-out and disc thickness variation for smooth, vibration free stopping
- Precision Balance
- Precision balance for vibration free performance
CENTRIC 120.33003 Specifications
Product Attributes
| Disc Mounting [cntrc] | Floating |
| Weight [cntrc] Kgs | 3.430 |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Weight [cntrc] Lbs | 7.540 |
| Misc Holes [cntrc] | 1 |
| Product Grade [cntrc] | Premium |
| Discard Thickness | 0.394 IN |
| Discard Thickness | 10.000 MM |
| Nominal Thickness | 0.469 IN |
| Nominal Thickness | 11.900 MM |
| Hat Finish | Painted |
| Overall Height | 1.382 IN |
| Overall Height | 35.100 MM |
| Outside Diameter | 9.409 IN |
| Outside Diameter | 239.000 MM |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Solid |
| Bearings Included | No |
| Center Hole Diameter | 65.000 MM |
| Center Hole Diameter | 2.559 IN |
| Mounting Bolt Hole Circle Diameter | 100.000 MM |
| Mounting Bolt Hole Circle Diameter | 3.937 IN |
| Stud/Lug Hole Quantity | 4 |
| Stud/Lug Hole Diameter | 0.512 IN |
| Stud/Lug Hole Diameter | 13.000 MM |
CENTRIC 120.33003 Cross References
CENTRIC 120.33003 Fits Vehicles
- Volkswagen Fox (1987-1993)
- Volkswagen Golf (1985-1998)
- Volkswagen Quantum (1982-1988)
- Audi Coupe (1981-1982)
- Volkswagen Rabbit Pickup (1980-1983)
- Volkswagen Rabbit Convertible (1980-1982)
- Volkswagen Jetta (1980-1998)
- Audi 4000 (1980-1984)
- Volkswagen Scirocco (1975-1984)
- Volkswagen Rabbit (1975-1984)
- Audi Fox (1973-1979)
- Volkswagen Dasher (1974-1981)
