CENTRIC 120.20016 Part Description
Manufacturer
Features & Benefits
- Painted hat and outer edge for corrosion resistance
- Painted Hat and Outer Edge
- Optimal Surface Finish
- Optimal surface finish for consistent stopping feel from the first stop
- Advanced Metallurgy
- Advanced metallurgy for optimal heat transfer and structural strength
- OE Vane Design and Plate Thickness
- OE vane design and plate thickness for heat capacity and strength
- Low Initial Lateral Run-Out
- Low initial lateral run-out and disc thickness variation for smooth, vibration free stopping
- Precision Balance
- Precision balance for vibration free performance
CENTRIC 120.20016 Specifications
Product Attributes
| Max Pb Drum Dia [cntrc] Mm | 6.200 |
| Vane Style [cntrc] | Straight |
| Misc Holes [cntrc] | 5 |
| Weight [cntrc] Lbs | 32.890 |
| Max Pb Drum Dia [cntrc] In | 0.244 |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Disc Mounting [cntrc] | Floating |
| Weight [cntrc] Kgs | 14.950 |
| Product Grade [cntrc] | Premium |
| Discard Thickness | 0.866 IN |
| Discard Thickness | 22.000 MM |
| Nominal Thickness | 24.000 MM |
| Nominal Thickness | 0.945 IN |
| Hat Finish | Painted |
| Overall Height | 47.100 MM |
| Overall Height | 1.854 IN |
| Outside Diameter | 11.811 IN |
| Outside Diameter | 300.000 MM |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Nominal Drum Diameter | 154.900 MM |
| Nominal Drum Diameter | 6.098 IN |
| Bearings Included | No |
| Center Hole Diameter | 63.500 MM |
| Center Hole Diameter | 2.500 IN |
| Mounting Bolt Hole Circle Diameter | 4.252 IN |
| Mounting Bolt Hole Circle Diameter | 108.000 MM |
| Stud/Lug Hole Quantity | 5 |
| Stud/Lug Hole Diameter | 13.750 MM |
| Stud/Lug Hole Diameter | 0.541 IN |
CENTRIC 120.20016 Cross References
CENTRIC 120.20016 Fits Vehicles
- Ford Mondeo (2001-2007)
- Jaguar X-Type (2002-2008)
