SPICER 5006813 Part Description
Manufacturer
Product Description
Axle Shaft Universal Joint Non-Greaseable AAM 1485WJ SPL Series ISR
Features & Benefits
- Journal cross is engineered with a solid cold-formed body to ensure better wear and overall strength.
- Bearing cups are heat treated for strength; precision-ground and case-hardened for durability.
- Multi-lip seal keeps grease in and contaminants out, and gets maximum retention in a wider range of environments.
- Thrust washers eliminate metal-to-metal contact, prevent wear and lower the overall operating temperature.
Universal Joint
SPICER 5006813 Specifications
Product Attributes
| OEM Mfg | AAM |
| OEM Series | AAM 1485WJ |
| Type | ISR Style |
| Bearing Cap Diameter (2) | 1.375 IN |
| Bearing Cap Type | Round with ISR Groove |
| Snap Ring Included | Yes |
| Snap Ring Type | Internal |
| Bearing Cap Diameter (1) | 1.375 IN |
| Material | Steel |
| Grease Zerk Included | Not Required |
| Pre Greased | Yes |
| Bearing Cap Finish | Ground |
| Coating Type | None |
| Grease Type | N.L.G.I. Grade 2 |
| Model Number | AAM 1485WJ |
| Seal Color/Finish | Black |
| Seal Material | Rubber |
| Greaseable | No |
| Bearing Cap Diameter A (mm) | 34.925 MM |
| Bearing Cap Diameter B (mm) | 34.925 MM |
| Bearing Cap Type A | ISR |
| Bearing Cap Type B | ISR |
| Hardware Included | No |
| Length A (In) | 2.920 IN |
| Length A (mm) | 74.168 MM |
| Length B (In) | 2.920 IN |
| Length B (mm) | 74.168 MM |
| Mounting Hardware Included | No |
| Distance Btw Snap Ring Grooves | 2.920 |
| Distance Btw Snap Ring Grooves (ISR) (2) | 2.920 |
Additional Information
| Harmonized Tariff Code (HTS) | 8708996810 |
| Country of Origin (Primary) | US |
| UPC | 00023913121204 |
| VMRS Code | 024002046 |
SPICER 5006813 Cross References
| Brand | Part Number |
|---|---|
| ACDelco | 45U0305 |
| American Axle & Manufacturing | 74081485 |
| Chrysler | 05086665AC, 5086 665AB, 5086 665AC, 5086665AA, 5086665AB, 5086665AC, 5086665AE |
| DANA | 25-5006813 |
| Daimler Truck North America | SP 5006813 |
| Dana Commercial Vehicle Service Parts | 5-3231X |
| Freightliner | SP 5006813 |
| GMB | 210-0464 |
| International Harvester (IHC) | E5006813 |
| MOOG | 464 |
| MOOG Chassis Products | 464 |
| Mack | 2104-5006813 |
| MasterPro | 464 |
| McNeilus | 1476827 |
| NEAPCO | 3-0485 |
| Navistar | DS5006813, E5006813 |
| Neapco OE Series | 30485, 3-0485 |
| Precision | 464 |
| SKF | 3-0485, UJ464 |
| SVL | 15-5006813 |
| Spicer | 5-3231X |
| Volvo | SP 5006813 |
