REACH COOLING 41-13541 Radiator

41-13541 by REACH COOLING - Radiator
REACH COOLING
Tap to view 4 more

No Stock Available

We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.

We may have similar parts for sale. Search Alternatives >

REACH COOLING 41-13541 Part Description

Manufacturer

REACH COOLING

Product Description

Radiator

Application Summary

Ford:2014-2019 Police Interceptor Sedan/2018-2019 Taurus

Features & Benefits

  • Thermal expansion reduce failure rates by allowing improved core expansion and contraction.
  • Radiators are the foundation of any engine cooling system. Tasked with preventing the vehicle from overheating, the radiator is vital to keeping vehicles up and running.
  • Reach utilizes longer header tabs for increased pressure resistance, this reduces the potential for tank-to-header leaks.
  • Thermal expansion cuts allow for longer life and reduce failure rates by allowing improved core expansion and contraction during normal heat cycles.
  • Our fin edges are folded for increased stability and heat disbursement properties.
  • We design and manufacture all our radiators to meet or even exceed Original Equipment specifications. We take pride in producing the most reliable replacement parts in the market.
  • Our included "multi-fit" attachments allow one radiator to cover multiple vehicle applications without sacrificing OE fit. This results in wider vehicle coverage with substantially less inventory.
  • Reach B-Type tubes feature central reinforcement to provide greater tolerance to pressure reducing the probability of tube failure.
  • Folded fin edges increase stability and heat disbursement properties.
  • Our B-Type tubes feature central reinforcement to provide greater tolerance to pressure. Stronger tube design means drastically reduced probability of tube failure.
  • Deep extrusion headers provide a stronger tube-to-header joint that is more resistant to the effects of vibration and thermal tube expansion.
  • Our deep extrusion header provides a stronger tube to header joint which is more resistant to the effects of vibration and thermal tube expansion, virtually eliminating tube to header leaks.
  • We use longer header tabs for increased pressure resistance. This reduces the potential for tank to header leaks.
  • Our B-Type tubes feature central reinforcement to provide greater tolerance to pressure. Stronger tube design means drastically reduced probability of tube failure.
  • Our B-Type tubes feature central reinforcement to provide greater tolerance to pressure reducing the probability of tube failure.
  • Our utilizes longer header tabs for increased pressure resistance, this reduces the potential for tank-to-header leaks.

REACH COOLING 41-13541 Specifications

Product Attributes

Core Height 28.75 IN
Core Height 730.3 MM
Core Thickness 1 IN
Core Thickness 2 MM
Core Width 16.875 IN
Core Width 428.6 MM
Transmission Oil Cooler Included No
Radiator Cap Included No
Inlet Diameter 1.5 IN
Inlet Diameter 38.1 MM
Outlet Diameter 1.5 IN
Outlet Diameter 38.1 MM
Engine Oil Cooler Included No
Core Row Quantity 1
Inlet Diameter 38.1 mm
Inlet Location Bottom Right
Tank Material Plastic
Outlet Diameter 38.1 MM
Down Flow Or Cross Flow Type Cross Flow
Core Thickness 25.4 MM
Core Width 428.625 MM
Core Material Aluminum
Outlet Location Top Left
Core Height 730.25 MM

Additional Information

Stock Status N
Country of Origin (Primary) TH
UPC 08859869511507
VMRS Code 042002001
UNSPSC 25174002

REACH COOLING 41-13541 Cross References

BrandPart Number
APDI RADS8012937
CRSCUC13541
CryoMAX13541
DPI DataPoint Inc13541
FVPRAD13541
Factory AirRAD13541
Federated13541
FordDG1Z-8005-E, DG1Z8005E, EG1Z 8005-C, EG1Z-8005-C, EG1Z8005C, 8G1Z8005A, 8A8Z8005A, 7T4Z8005A, AA5Z8005A, 8G1Z8005B
Northern RadiatorCR13541
OSC13541
PACIFIC BEST INC.PR13541A
Platinum ProRAD2937
RadCool13541
Spectra PremiumCU2937
TYGFD37166A
US Motor WorksUSR13541

REACH COOLING 41-13541 Fits Vehicles

  • Ford Taurus (2013-2019)
  • Ford Police Interceptor Sedan (2014-2019)
