(888) 312-8812 Login SignupGOODYEAR BELTS 28514 Accessory Drive Belt - V-Belt, 51.4 in. Effective Length, EPDM
Tap to view 3 more
$3249
Limited availability at this price!
In Stock
Get it by Wednesday, Mar 18
GOODYEAR BELTS 28514 Part Description
Manufacturer
Product Description
V-Belt
Features & Benefits
- Meets or Exceeds OEM Specifications
- EPDM Rubber Compound known for its excellent resistance to heat, ozone, weathering, and abrasion, ensuring long-lasting durability in automotive applications.
- Long-life EPDM Rubber Compound
- Radial Cogged design reduces bending resistance and improves power transmission efficiency, leading to enhanced performance and longevity, ensuring the longevity of automotive engine systems.
- Radial Cog design to eliminate stress risers that can cause cracking
- Polyester Cord Reinforcement, providing superior tensile strength and resistance to stretching, ensuring reliable power transmission and reduced maintenance.
- Proprietary rubber formulation for quiet operation
- Precision ground sides helps reduce noise and vibration in automotive engine systems, enhancing overall driving comfort and smoothness.
- Precision ground sides for maximum pulley contact
- Temperature Resistance, suitable for automotive applications, these belts maintain their performance even in extreme operating conditions.
- High strength tensile cords designed for minimal tension decay and low maintenance
- Limited Lifetime Warranty
GOODYEAR BELTS 28514 Specifications
Product Attributes
| Belt Material | EPDM |
| Item Weight (kg) | 0.35 KG |
| Item Weight (lbs) | 0.77 LB |
| Cord Material | Polyester |
| Effective Length | 51.4 in |
| Effective Length | 1306 mm |
| Outside Circumference | 51.97 in |
| Outside Circumference | 1320 mm |
| Profile Series | 28 |
| Rib Angle | 36⁰ DD |
| Thickness (in) | 0.492 In |
| Thickness (mm) | 12.5 mm |
| Top Width (in) | 0.846 IN |
| Top Width (mm) | 21.5 MM |
| V-belt Profile | 20A |
| Angle | 36 DD |
| Color | Black |
| Construction | Cogged |
| Cross Section Designation | 20A |
| Grade Type | OE Performance |
| Notched | Yes |
| Profile Type | 28 |
| Sae Standard | J636 |
| SAE Standard | J637 |
| Strand Quantity | 1 |
| Thickness | 0.492 IN |
| Thickness | 12.5 MM |
| Top Cogged | No |
| Top Width | 0.846 in |
| Top Width | 21.5 mm |
| Type | Automotive V-Belt |
Additional Information
| Stock Status | S |
| Warranty Time | 1 |
| Warranty Special | 1 Year Limited Warranty |
| Warranty Time UOM | YR |
| Warranty Special UOM | TX |
| Country of Origin (Primary) | IN |
| Harmonized Tariff Code (HTS) | 4010390000 |
| Harmonized Tariff Code (Schedule B) | 4010390000 |
| Canadian Harmonizing Tariff Code | 4010390000 |
| UPC | 00195199102243 |
| VMRS Code | 065005003 |
| UNSPSC | 26111801 |
GOODYEAR BELTS 28514 Cross References
| Brand | Part Number |
|---|---|
| Armormark | 20A1300 |
| CONTINENTAL AG | 28517 |
| CONTINENTAL/CONTITECH | 28517 |
| Cartek | CK28514 |
| Continental | 28517 |
| DAYCO | 28515 |
| Dayco | 20A1300 |
| GATES | TR28514 |
| OEM PART NUMBER | 23-12160-515, 208043504517, C6JZ-8260-C, 88GB442P517, 575819-C91, 478578-C91, D1102-5863, 575817-C1, 575819-C1, 306632-R1, 73148503, V1091052, 8001928, 3040393, 9031245, 700227A, GT28517, GTFL574, 178627, 178426 |
| OEM Part Number | 2.08044E+11, 20A1300 |
GOODYEAR BELTS 28514 Fits Vehicles
- International F5070-WW (1993)
- International F5070-SF (1985-1987)
- International F5070 (1985-1993)
- International 5070 (1985-1993)
- Western Star WSH (1982-1983)
- Western Star 6900 (1989-1990)
- Western Star 4900 (1981-1990)
- Western Star 4800 (1981-1990)
- International 9800 SBA (1996)
- International 8100 (1995-1996)
- International 9700 (1990-1994, 1996)
- International 8300 (1990-1994)
- International 8200 (1990-1996)
- International 9600 (1990-1993, 1996)
- International 9400 (1990-1993, 1995-1996)
- International 5000 (1990-1993)
- International COF5870 Paystar (1988)
- International 9300 (1988-1993, 1995-1996)
- Suzuki Aerio (2002)
- Ford CLT9000 (1981-1989)
- Ford CL9000 (1981-1989)
- Studebaker President FE (1930)
- Studebaker President Model 80 (1931)
- Studebaker President Model 91 (1932)
- Studebaker President Speedway Model 92 (1933)
- Nash Ambassador (1933-1934)
