(888) 312-8812 Login SignupCENTRIC 120.61126 Centric Premium Brake Rotor
Tap to view 4 more
*Representative image - actual part not displayed
No Stock Available
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
CENTRIC 120.61126 Part Description
Manufacturer
Product Description
Centric Premium Brake Rotor
Application Summary
Lincoln MKZ 2020-2017
Features & Benefits
- Symmetric vane; split-core castings for uniform heat distribution. Black E-Coat anti-corrosive coating protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life
- Painted hat and outer edge for corrosion resistance
- Painted Hat and Outer Edge
- Optimal Surface Finish
- Optimal surface finish for consistent stopping feel from the first stop
- Advanced Metallurgy
- Advanced metallurgy for optimal heat transfer and structural strength
- OE Vane Design and Plate Thickness
- OE vane design and plate thickness for heat capacity and strength
- Low Initial Lateral Run-Out
- Low initial lateral run-out and disc thickness variation for smooth, vibration free stopping
- Precision Balance
- Precision balance for vibration free performance
Premium rotor; rotors; Centric; brake rotor; break; brake disc; disc brake
CENTRIC 120.61126 Specifications
Product Attributes
| Discard Thickness | 26.500 MM |
| Nominal Thickness | 28.000 MM |
| Hat Finish | Painted |
| Overall Height | 2.000 IN |
| Outside Diameter | 316.000 MM |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Bearings Included | No |
| Center Hole Diameter | 2.500 IN |
| Mounting Bolt Hole Circle Diameter | 4.252 IN |
| Stud/Lug Hole Quantity | 5 |
| Stud/Lug Hole Diameter | 0.606 IN |
| California Proposition 65 Text [basic] | WARNING: Cancer and Reproductive Harm |
| Disc Mounting [cntrc] | Floating |
| Hat Id [cntrc] In | 5.492 |
| Hat Id [cntrc] Mm | 139.500 |
| Misc Holes [cntrc] | 5 |
| OEM Vane Count [cntrc] | 53 |
| Vane Style [cntrc] | Straight |
| Weight [cntrc] Kgs | 10.760 |
| Weight [cntrc] Lbs | 23.750 |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Product Grade [cntrc] | Premium |
| Discard Thickness | 1.043 IN |
| Nominal Thickness | 1.102 IN |
| Overall Height | 50.800 MM |
| Outside Diameter | 12.441 IN |
| Center Hole Diameter | 63.500 MM |
| Mounting Bolt Hole Circle Diameter | 108.000 MM |
| Stud/Lug Hole Diameter | 15.400 MM |
Additional Information
| Country of Origin (Primary) | CN |
| NAFTA Preference Criterion Code | B |
| UPC | 00889590293777 |
CENTRIC 120.61126 Cross References
CENTRIC 120.61126 Fits Vehicles
- Lincoln MKZ (2017-2020)
