(888) 312-8812 Login SignupUNIVERSAL AIR CONDITIONER (UAC) CO4861 A/C Compressor -- Sanden SD7H15 Compressor Assembly
*Representative image - actual part not displayed
No Stock Available
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
UNIVERSAL AIR CONDITIONER (UAC) CO4861 Part Description
UNIVERSAL AIR CONDITIONER (UAC) CO4861 Specifications
Product Attributes
| Displacement | 155 |
| Grooves | 2 |
| Connector | 1 Wire Male Packard #12015791 |
| Rotation | CW |
| Refrigerant | R134A |
| Voltage | 12 |
| Compressor Type | SD7H15 |
| Clocking | Rear |
| Cylinder Head | GV |
| Pulley Diameter (mm) | 125 |
| Gauge Line (mm) | 40 |
| Compressor Mount | Ear |
| Style | HD |
| Ear ID | 83.3 |
| Gauge Line to End Groove | 39.55 |
| Gauge Line to First Groove | 23.8 |
| Head Port Style | O-Ring |
| Oil Qty (cc) | 200 |
| Port Angle | H |
Additional Information
| Country of Origin (Primary) | US |
| UPC | 00711307248902 |
