(888) 312-8812 Login SignupATE BRAKE PRODUCTS 425197 ATE Original Front Disc Brake Rotor 425197 for Volvo
No Stock Available
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
ATE BRAKE PRODUCTS 425197 Part Description
Manufacturer
Product Description
ATE Original Front Disc Brake Rotor 425197 for Volvo
Features & Benefits
- Application specific design is engineered to tighter tolerances
- Protective coating ensures long lasting corrosion resistance
- High carbon brake disc optimize durability and prevents brake judder and noise
- Use of state of the art original replacement part materials in the production of the rotors
ATE BRAKE PRODUCTS 425197 Specifications
Product Attributes
| Outside Diameter | 320.00 MM |
| Inside Diameter | 148.00 MM |
| Nominal Thickness | 25.00 MM |
| Discard Thickness | 23.00 MM |
| Solid Or Vented Type Rotor | Vented |
| Surface Type | Smooth |
| Construction | Full Cast |
| Rust Resistant Coating | Yes |
| Overall Height | 48.50 MM |
| Material | High-carbon |
| ABS Tone Ring Included | No |
| Bearings Included | No |
| Stud/Lug Hole Circle Diameter | 108.00 MM |
| Stud/Lug Hole Quantity | 5 |
| Stud/Lug Hole Diameter | 13.70 MM |
| Center Hole Diameter | 63.50 MM |
| Directional or Non-Directional Brake Surface | Non-Directional |
Additional Information
| Country of Origin (Primary) | CN |
| EU | |
| UPC | 04006633346191 |
ATE BRAKE PRODUCTS 425197 Cross References
| Brand | Part Number |
|---|---|
| Aimco | 34349 |
| Bendix | 562434B, PRT5962 |
| Bosch | 0 986 479 310, 0 986 479 C75, 52011379 |
| Brembo | 09.9468.11, 09.9468.14, 09.A728.10, 09.A728.11, 09.A728.1X, 09.C542.21 |
| Delphi | BG4056 |
| Ferodo America | DDF1649, DDF1649C-1 |
| Hella | 54491, 8DD 355 113-001 |
| Raybestos Brakes | 980552 |
| Textar | 92149100, 92282103, 98200 1491 0 1 |
| Valeo | 197143 |
| Volvo | 274521, 2745210, 3126272, 31262720, 312627200, 31302573, 313025730, 31329122, 313291220, 31400942, 314009420 |
| Wagner Brake | BD180000 |
| Zimmermann | 610.3709.00, 610.3709.50 |
ATE BRAKE PRODUCTS 425197 Fits Vehicles
- Volvo C70 (2006-2013)
- Volvo V50 (2005-2011)
- Volvo S40 (2004-2011)
ATE BRAKE PRODUCTS 425197 Customer Reviews
No reviews yet
Be the first to review this product!
ATE BRAKE PRODUCTS 425197 Questions & Answers
No questions yet
Be the first to ask a question about this product!
