ATE BRAKE PRODUCTS 425170 Part Description
Manufacturer
Product Description
ATE Original Front Disc Brake Rotor 425170 for Mazda
Features & Benefits
- Application specific design is engineered to tighter tolerances
- Protective coating ensures long lasting corrosion resistance
- High carbon brake disc optimize durability and prevents brake judder and noise
- Use of state of the art original replacement part materials in the production of the rotors
ATE BRAKE PRODUCTS 425170 Specifications
Product Attributes
| Outside Diameter | 300.00 MM |
| Inside Diameter | 140.00 MM |
| Nominal Thickness | 25.00 MM |
| Discard Thickness | 23.00 MM |
| Solid Or Vented Type Rotor | Vented |
| Surface Type | Smooth |
| Construction | Full Cast |
| Rust Resistant Coating | Yes |
| Overall Height | 48.50 MM |
| Material | High-carbon |
| ABS Tone Ring Included | No |
| Bearings Included | No |
| Stud/Lug Hole Circle Diameter | 114.30 MM |
| Stud/Lug Hole Quantity | 4 |
| Stud/Lug Hole Diameter | 14.00 MM |
| Center Hole Diameter | 72.00 MM |
| Directional or Non-Directional Brake Surface | Non-Directional |
Additional Information
| Country of Origin (Primary) | IT |
| EU | |
| UPC | 04006633227865 |
ATE BRAKE PRODUCTS 425170 Cross References
| Brand | Part Number |
|---|---|
| Aimco | 31363 |
| Bosch | 0 986 479 183 |
| Brembo | 09.9468.20, 09.9468.21, 09.9468.2X, 09.9468.76, FS.192.000 |
| Delphi | BG3928 |
| Febi-Bilstein | 32770 |
| Ferodo America | DDF1312, DDF1312-1, DDF1312C |
| Hella | 54304, 8DD 355 110-891 |
| Mazda | BP6Y3325XB, BP6Y3325XD, BP6Y3325XE, BP6Y3325XF, C26Y3325XA, C26Y3325XB, C26Y3325XC, C26Y3325XD |
| Raybestos Brakes | 980283 |
| TRW | DF4385 |
| Textar | 92130400, 98200 1304 0 1 |
| Valeo | 197365 |
| Wagner Brake | BD126328 |
| Zimmermann | 370.3077.00, 370.3077.20 |
ATE BRAKE PRODUCTS 425170 Fits Vehicles
- Mazda 5 (2006-2010, 2012-2015)
- Mazda 3 (2004-2013)
