(888) 312-8812 Login SignupREACH COOLING 31-4502 A/C Condenser
Tap to view 3 more
No Stock Available
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
REACH COOLING 31-4502 Part Description
Manufacturer
Product Description
A/C Condenser
Application Summary
Mercedes-Benz:90-93 300CE/ 300D/ 300E/ 300TE/95 E300/94-95 E320
Features & Benefits
- Our fin edges are folded for increased stability and heat disbursement properties.
- Tube-and-fin configuration strictly follows OEM design to ensure maximum heat transfer and performance during pressure drop.
- All brackets and fittings are made with virgin aluminum to ensure purity of material and strength in brazing bond.
- Our tubes feature a 5mm fin height which allows for a greater cooling surface.
- Reach condensers feature a parallel flow design to increase cooling efficiency.
- All our tubes are zinc coated to better handle salt corrosion, especially for areas near the coast or with heavy snow.
- Reach condensers are designed and manufactured with OE performance and fit as our top priority. By utilizing topnotch materials, designs, and manufacturing techniques, we ensure that our condensers have the best quality and reliability.
- Our condensers are designed and manufactured with OE performance and fit as our top priority. By utilizing topnotch materials, designs, and manufacturing techniques, we ensure that our condensers have the best quality and reliability.
- Our condensers feature a parallel flow design to increase cooling efficiency.
No Shipping Restriction
condenser, condenser for car, ac condenser unit, ac condenser car, condenser ac
REACH COOLING 31-4502 Specifications
Product Attributes
| Core Thickness | 18 MM |
| Core Width | 428 MM |
| Core Length | 520 MM |
| Inlet Fitting Type | Male O-Ring |
| Outlet Fitting Type | Male O-Ring |
| Mounting Hardware Included | Seals and Gaskets not included |
| Condenser Core Type | Parallel Flow |
| Includes Drier | No |
| Core Thickness | 0.71 IN |
| Core Width | 16.85 IN |
| Core Length | 20.47 IN |
| Inlet Diameter | 0.339 IN |
| Core Material | Aluminum |
| Inlet Diameter | 8.6 MM |
| Outlet Diameter | 14.5 MM |
| Outlet Diameter | 0.571 IN |
Additional Information
| Warranty Time | 24 |
| Harmonized Tariff Code (Schedule B) | 8415909000 |
| Warranty Special UOM | TX |
| Harmonized Tariff Code (HTS) | 8415908045 |
| Country of Origin (Primary) | CN |
| Warranty Distance | 24000 |
| Warranty Time UOM | MO |
| UPC | 06941099994280 |
| VMRS Code | 001001062 |
REACH COOLING 31-4502 Cross References
| Brand | Part Number |
|---|---|
| AIRCON | A1442 |
| APDI | 7014502 |
| APDI RADS | 7014502 |
| Advance Auto Parts | 6979 |
| American Condenser by Vista-Pro | 1034163, P34163, P34163P |
| AutoZone | 7-4502 |
| Autokool | 4403 |
| BEHR | 351035771 |
| CRS | AC34163, AC4502 |
| CSF | 10107 |
| CryoMAX | 0A004502PFYH, 4502 |
| DPI DataPoint Inc | 4502 |
| Delphi | TSP0225041 |
| Dixin USA | DX4502 |
| FVP | CON4502 |
| Factory Air | CON4502 |
| Federated | 4502 |
| Four Seasons | 40482, 53921, 10107 |
| GLOBAL PARTS DISTRIBUTORS | 4502C |
| Gilmore Products | AUC4502 |
| Global Heat Transfer | 4502 |
| Hella | 351035771 |
| Keystone Auto Industries | CND34163 |
| Mercedes-Benz | 1248301670, 1408300170, A1248301670, A1408300170 |
| Murray Heat Transfer | 7-4502 |
| NAPA | 1K600149, NC4502B |
| Nissens | 94377 |
| Northern Factory Sales | CD34163 |
| Northern Radiator | CD34163 |
| OSC | 4502, 74502 |
| Omega | 24-30035, 2430035 |
| Omega Environmental Technologies | 2430035 |
| PACIFIC BEST INC. | PC4502F |
| PACO | PL3059 |
| Partslink | MB3030113 |
| Performance Radiator | 4502 |
| Platinum Pro | CND34163 |
| Proliance | 634163 |
| RadCool | 4502 |
| Rahn Industries | 34163 |
| Silla Cooling | C4502 |
| Spectra Premium | 7-4502, 74502 |
| Sunbelt Radiators Inc | SBC-4502 |
| Thermal Solutions Manufacturing | 6979 |
| UAC | CN4502PF, CN 4502PF |
| Valeo | 816901 |
| Vista Pro | 634163, 6979 |
REACH COOLING 31-4502 Fits Vehicles
- Mercedes-Benz E320 (1994-1995)
- Mercedes-Benz E300 (1995)
- Mercedes-Benz 300TE (1990-1993)
- Mercedes-Benz 300E (1990-1993)
- Mercedes-Benz 300D (1990-1993)
- Mercedes-Benz 300CE (1990-1993)
