REACH COOLING 41-13581 Radiator

41-13581 by REACH COOLING - Radiator
REACH COOLING
Tap to view 4 more

No Stock Available

We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.

We may have similar parts for sale. Search Alternatives >

REACH COOLING 41-13581 Part Description

Manufacturer

REACH COOLING

Product Description

Radiator

Application Summary

BMW:2012-2015 335i/2011-2015 335i xDrive/2014-2016 435i/2015-2016 435i Gran Coupe/2014-2016 435i xDrive/2015-2016 435i xDrive Gran Coupe/2016-2018 M2

Features & Benefits

  • Deep extrusion headers provide a stronger tube-to-header joint that is more resistant to the effects of vibration and thermal tube expansion.
  • Radiators are the foundation of any engine cooling system. Tasked with preventing the vehicle from overheating, the radiator is vital to keeping vehicles up and running.
  • Reach B-Type tubes feature central reinforcement to provide greater tolerance to pressure reducing the probability of tube failure.
  • Reach utilizes longer header tabs for increased pressure resistance, this reduces the potential for tank-to-header leaks.
  • Thermal expansion reduce failure rates by allowing improved core expansion and contraction.
  • Folded fin edges increase stability and heat disbursement properties.
  • Our B-Type tubes feature central reinforcement to provide greater tolerance to pressure. Stronger tube design means drastically reduced probability of tube failure.
  • Our deep extrusion header provides a stronger tube to header joint which is more resistant to the effects of vibration and thermal tube expansion, virtually eliminating tube to header leaks.
  • Our included "multi-fit" attachments allow one radiator to cover multiple vehicle applications without sacrificing OE fit. This results in wider vehicle coverage with substantially less inventory.
  • We use longer header tabs for increased pressure resistance. This reduces the potential for tank to header leaks.
  • Our fin edges are folded for increased stability and heat disbursement properties.
  • Thermal expansion cuts allow for longer life and reduce failure rates by allowing improved core expansion and contraction during normal heat cycles.
  • We design and manufacture all our radiators to meet or even exceed Original Equipment specifications. We take pride in producing the most reliable replacement parts in the market.
  • Our B-Type tubes feature central reinforcement to provide greater tolerance to pressure. Stronger tube design means drastically reduced probability of tube failure.
  • Our utilizes longer header tabs for increased pressure resistance, this reduces the potential for tank-to-header leaks.
  • Our B-Type tubes feature central reinforcement to provide greater tolerance to pressure reducing the probability of tube failure.

REACH COOLING 41-13581 Specifications

Product Attributes

Core Width 13.31 IN
Core Thickness 32 MM
Outlet Diameter 1.53 IN
Transmission Oil Cooler Included No
Radiator Cap Included No
Core Height 600 MM
Inlet Diameter 1.53 IN
Engine Oil Cooler Included No
Core Width 600.075 MM
Tank Material Plastic
Core Thickness 34.925 MM
Core Width 338 MM
Inlet Diameter 38.8 MM
Inlet Location Top Left
Core Height 336.55 MM
Inlet Diameter 38.1 mm
Core Height 23.62 IN
Outlet Diameter 38.8 MM
Core Row Quantity 1
Core Material Aluminum
Outlet Location Center Right
Core Thickness 1.26 IN
Outlet Diameter 38.1 MM
Down Flow Or Cross Flow Type Cross Flow

Additional Information

Country of Origin (Primary) TH
UPC 06941278944327
VMRS Code 042002001
UNSPSC 25174002

REACH COOLING 41-13581 Cross References

BrandPart Number
BMW17 11 7 600 535, 17 11 7 606 017, 17 11 7 628 057, 17 11 8 672 103, 17117600535, 17117606017, 17117628057, 17118672103
CRSCUC13581
CRYOMAX COOLING SYSTEM CORP0ABW6616Z
CSF3829
CryoMAX13581, 0R-013581-A3CM, 0ABW6616, 0R013581A3CM
DPI DataPoint Inc13581
Factory AirRAD13581
Factory Motor PartsRAD13581
Federated13581
OSC13581
PACIFIC BEST INC.PR13581A
PartslinkBM3010180
Platinum ProRAD13581
RadCool13581
Spectra PremiumCU13581
Sunbelt Radiators IncSBR13581
TYGBM37021C
US Motor WorksUSR13581

REACH COOLING 41-13581 Fits Vehicles

  • BMW M235i xDrive (2015-2016)
  • BMW M235i (2014-2016)
  • BMW 335i (2012-2015)
