REACH COOLING 31-3797 A/C Condenser

31-3797 by REACH COOLING - A/C Condenser
REACH COOLING
Tap to view 4 more

No Stock Available

We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.

We may have similar parts for sale. Search Alternatives >

REACH COOLING 31-3797 Part Description

Manufacturer

REACH COOLING

Product Description

A/C Condenser

Application Summary

Lexus:2010-2015 RX450h

Features & Benefits

  • Our fin edges are folded for increased stability and heat disbursement properties.
  • Tube-and-fin configuration strictly follows OEM design to ensure maximum heat transfer and performance during pressure drop.
  • All our tubes are zinc coated to better handle salt corrosion, especially for areas near the coast or with heavy snow.
  • Reach condensers feature a parallel flow design to increase cooling efficiency.
  • All brackets and fittings are made with virgin aluminum to ensure purity of material and strength in brazing bond.
  • Our tubes feature a 5mm fin height which allows for a greater cooling surface.
  • Reach condensers are designed and manufactured with OE performance and fit as our top priority. By utilizing topnotch materials, designs, and manufacturing techniques, we ensure that our condensers have the best quality and reliability.
  • Our condensers are designed and manufactured with OE performance and fit as our top priority. By utilizing topnotch materials, designs, and manufacturing techniques, we ensure that our condensers have the best quality and reliability.
  • Our condensers feature a parallel flow design to increase cooling efficiency.

No Shipping Restriction

condenser, air conditioning, ac condenser, a/c, cond, parallel flow, accumulator

REACH COOLING 31-3797 Specifications

Product Attributes

Outlet Location Lower Left
Core Length 28.15 IN
Condenser Core Type Parallel Flow
Inlet Location Upper Left
Mounting Hardware Included Seals and Gaskets not included
Core Thickness 0.87 IN
Core Width 306.3 MM
Includes Drier Yes
Core Thickness 22 MM
Core Length 715 MM
Core Width 12.06 IN
Outlet Diameter 0.61 IN
Core Material Aluminum
Inlet Location Top Left
Outlet Diameter 15.5 MM
Outlet Location Bottom Left
Inlet Diameter 0.4 IN
Inlet Diameter 10.15 MM

Additional Information

Country of Origin (Primary) CN
UPC 06949521757830

REACH COOLING 31-3797 Cross References

BrandPart Number
APC203797
APC Inc203797
APDI7013797
APDI RADS7013869
AutoNation6708-00937
AutoZone7-3797
CRSAC3797
CSF10729
CryoMAX30067, 3797
DENSO4770644
DPI DataPoint Inc30067, 3797
FVPCON3797
Factory AirCON3797
Federated3797
Four Seasons40733
GLOBAL PARTS DISTRIBUTORS3797C
Genera - Archived3797
Kool VueKVAC3797
KoyoCD010497
Lexus8846048150, 8846048290, 8846048280
Murray Heat Transfer7-3797
NAPA73797, NC3797A
Northern Factory SalesCD82111
Northern RadiatorCD82111
OEM8846048280, 8846048290
OSC30067, 3797
PACIFIC BEST INC.PC30067, PC3797
PBIPC3797P
PartslinkLX3030124
Platinum ProCND3797
RadCool3797
Spectra Premium7-3797, 73797, 7-30067
Sunbelt Radiators IncSBC-3797
TYC3797
TYGTY39191A
Tongshi8875103
Toyota8846048150
UACCN 3797PFC, CN3797PFC
Vision3797P
XINTIANAC95605

REACH COOLING 31-3797 Fits Vehicles

  • Lexus RX450h (2010-2015)
