RAYBESTOS 980608R Part Description
Manufacturer
Product Description
Raybestos R-Line Brake Rotor
Application Summary
2009-2007 Volvo S80 Rear, 2008 Volvo XC70 Rear
Features & Benefits
- OE Fit, Form, and Function
- Developed from OE samples and made with G3000-qualified material, ensuring OE fit, form and function for dependable braking.
- SAE Standard
- R-Line Rotors meet the SAE standard for tensile strength, providing structural integrity and a maximum service life.
- Low Initial Lateral Runout and Thickness Variation
- R-Line Rotors have a small parameter lateral runout and a thickness variation ensuring less pedal pulsation, less brake noise, and an extended pad life.
- Mill Balanced Edges
- R-Line Rotors are mill balanced and 100 percent validated. This helps minimize the thickness variation on the rotor and leads to minimized vibration and smoother stopping.
RAYBESTOS 980608R Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 2.504 IN |
| Center Hole Diameter | 63.6 MM |
| Conventional Or Drum-In-Hat Type Rotor | Drum-In-Hat |
| Discard Thickness | 0.394 IN |
| Discard Thickness | 10 MM |
| Harmonize Code | 8708.30.5030 |
| Inside Diameter | 8.406 IN |
| Inside Diameter | 213.5 MM |
| Mounting Bolt Hole Circle Diameter | 4.252 IN |
| Mounting Bolt Hole Circle Diameter | 108 MM |
| Mounting Bolt Hole Diameter | 0.62 IN |
| Mounting Bolt Hole Diameter | 15.75 MM |
| Mounting Bolt Hole Quantity | 5 |
| Nominal Thickness | 0.472 IN |
| Nominal Thickness | 12 MM |
| Outside Diameter | 11.882 IN |
| Outside Diameter | 301.8 MM |
| Overall Height | 2.717 IN |
| Overall Height | 69 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Solid |
| Stud/Lug Hole Diameter | 0.62 IN |
| Stud/Lug Hole Diameter | 15.75 MM |
| Stud/Lug Hole Quantity | 5 |
| Surface Type | Smooth |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708309990 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 00887213372595 |
RAYBESTOS 980608R Cross References
| Brand | Part Number |
|---|---|
| Advance Auto Parts | YH200953, YH200953C, YH200953P |
| AutoZone | 34758, 34758DG |
| BrakeBest | 52011375, 980608, 980608RGS |
| Brembo | 08.A536.11 |
| CENTRIC | 121.39043 |
| Centric Parts | 120.39041, 121.39041, 125.39041, 126.39041SL, 126.39041SR, 127.39041L, 127.39041R, 320.39041C |
| Dura Corp | BR34370 |
| DuraGo | BR34370 |
| Newtek Automotive USA | 34370 |
| Promax | 14-34370 |
| Qualis | 45695 |
| TRW | 4844 |
| Volvo | 30769058, 307690580 |
| WORLDPAC | 1407-75738, 1427-732075 |
| Winhere | 661786 |
RAYBESTOS 980608R Fits Vehicles
- Volvo XC70 (2008)
- Volvo S80 (2007-2011, 2016)
RAYBESTOS 980608R Customer Reviews
No reviews yet
Be the first to review this product!
RAYBESTOS 980608R Questions & Answers
No questions yet
Be the first to ask a question about this product!
