(888) 312-8812 Login SignupNTN WE61577 Wheel Bearing and Hub Assembly - Steel, Natural, with Wheel Studs
Tap to view 9 more
$43799
Limited Availability
Due to limited availability, we will confirm your order and notify you within 1 business day.
NTN WE61577 Part Description
Manufacturer
Product Description
OE form, fit & function wheel hub unit.
Features & Benefits
- All BCA applications that require ABS functionality utilize our custom-designed seals that are molded over with magnetic encoders (if required) to ensure proper ABS operation.
- Forged-steel construction provides the toughness and durability required for even the harshest applications.
- Rolling element cages reduce friction by keeping rolling elements spaced correctly, preventing damage and resulting in reduced operational temperatures.
- Application-specific components to ensure proper connection and performance of the ABS module and sensors.
- Pre-lubricated bearings, sealed for life with specialized grease provide longer life and a wider range of operational temperatures.
- Application-specific engineering reduces noise, vibration and harshness (NVH).
NTN WE61577 Specifications
Product Attributes
| Spline Quantity | 33 |
| Flange Included | Yes |
| Flange Bolt Hole Quantity | 4 |
| Wheel Pilot Diameter | 4.594 IN |
| Brake Pilot Diameter | 4.641 IN |
| Wheel Stud Quantity | 8 |
| Flange Shape | Modified Rectangular |
| Anti Lock Braking System | Yes |
| Drive Type | Driven |
| Bearing Type | Taper |
| Flange Offset | 2.297 IN |
| Flange Diameter | 199.3 MM |
| Bolt Circle Diameter | 6.500 IN |
| Anti Lock Braking System Type | Tone Ring with Sensor |
| Bearing Generation | Gen 3 |
| Knuckle Bolt Circle Diameter (Inches) | 5.512 |
| Knuckle Bolt Circle Diameter (Millimeters) | 140.0 |
| Knuckle Bolt Hole Size | M14X1.5 |
| Knuckle Pilot Hole Diameter | 4.167 IN |
| Wheel Stud Size | M14X1.5 MM |
Additional Information
| Country of Origin (Primary) | US |
| Harmonized Tariff Code (Schedule B) | 8708995800 |
| Warranty Time | 12 |
| Warranty Time UOM | MO |
| UPC | 662810615777 |
NTN WE61577 Cross References
| Brand | Part Number |
|---|---|
| ACDelco | FW335, FW368, FW391, 515099 |
| Autopart International | 1411334843 |
| CRS Automotive | NT515099 |
| DT Components | 515099 |
| Drive Tech America | NT515099 |
| DuraGo | 29515099 |
| Fenco | WH515099 |
| GMB | 7300352 |
| GSP | 106099 |
| General Motors | 20836877, 25964539, 15910969, 22740470 |
| MOOG Chassis Products | 515099 |
| MPA | WH515099 |
| Mevotech | H515099 |
| Parts Master | PM515099 |
| Parts Plus | P515099 |
| Precision Bearing | 515099 |
| Raybestos Brakes | 715099 |
| SKF | BR930783 |
| Schaeffler | FW799, WH1320, 102203 |
| Timken | SP580313 |
| WJB | WA515099 |
NTN WE61577 Fits Vehicles
- GMC Sierra 3500 HD (2007-2010)
- Chevrolet Silverado 3500 HD (2007-2010)
