REACH COOLING 41-75 Radiator

41-75 by REACH COOLING - Radiator
REACH COOLING
Tap to view 1 more

No Stock Available

We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.

We may have similar parts for sale. Search Alternatives >

REACH COOLING 41-75 Part Description

Manufacturer

REACH COOLING

Product Description

Radiator

Application Summary

Volkswagen:81-84 Jetta/81-83 Scirocco

Features & Benefits

  • Thermal expansion reduce failure rates by allowing improved core expansion and contraction.
  • Deep extrusion headers provide a stronger tube-to-header joint that is more resistant to the effects of vibration and thermal tube expansion.
  • Our fin edges are folded for increased stability and heat disbursement properties.
  • Radiators are the foundation of any engine cooling system. Tasked with preventing the vehicle from overheating, the radiator is vital to keeping vehicles up and running.
  • Reach B-Type tubes feature central reinforcement to provide greater tolerance to pressure reducing the probability of tube failure.
  • Reach utilizes longer header tabs for increased pressure resistance, this reduces the potential for tank-to-header leaks.
  • Thermal expansion cuts allow for longer life and reduce failure rates by allowing improved core expansion and contraction during normal heat cycles.
  • We design and manufacture all our radiators to meet or even exceed Original Equipment specifications. We take pride in producing the most reliable replacement parts in the market.
  • Folded fin edges increase stability and heat disbursement properties.
  • Our deep extrusion header provides a stronger tube to header joint which is more resistant to the effects of vibration and thermal tube expansion, virtually eliminating tube to header leaks.
  • Our included "multi-fit" attachments allow one radiator to cover multiple vehicle applications without sacrificing OE fit. This results in wider vehicle coverage with substantially less inventory.
  • We use longer header tabs for increased pressure resistance. This reduces the potential for tank to header leaks.
  • Our B-Type tubes feature central reinforcement to provide greater tolerance to pressure. Stronger tube design means drastically reduced probability of tube failure.
  • Our B-Type tubes feature central reinforcement to provide greater tolerance to pressure. Stronger tube design means drastically reduced probability of tube failure.
  • Our utilizes longer header tabs for increased pressure resistance, this reduces the potential for tank-to-header leaks.
  • Our B-Type tubes feature central reinforcement to provide greater tolerance to pressure reducing the probability of tube failure.

No Shipping Restriction

radiator, engine cooling, rad, car radiator, auto radiator, radiator cap

REACH COOLING 41-75 Specifications

Product Attributes

Core Height 20.687 IN
Core Height 525.5 MM
Core Thickness 1.312 IN
Core Thickness 33.3 MM
Core Width 12.687 IN
Core Width 322.3 MM
Inlet Header Length 13.625 IN
Inlet Header Length 346.1 MM
Outlet Header Length 12.75 IN
Outlet Header Length 323.9 MM
Core Material Aluminum
Outlet Location Bottom Right
Tank Material Plastic
Transmission Oil Cooler Included No
Inlet Header Width 2.5 IN
Inlet Header Width 63.5 MM
Outlet Header Width 2.5 IN
Outlet Header Width 63.5 MM
Radiator Cap Included No
Core Row Quantity 1
Inlet Diameter 1.25 IN
Inlet Diameter 31.8 MM
Inlet Location Top Right
Outlet Diameter 1.25 IN
Outlet Diameter 31.8 MM
Engine Oil Cooler Included No
Down Flow Or Cross Flow Type Cross Flow
Inlet Header Width 63.5 mm
Outlet Header Width 63.5 mm
Core Height 525.449 MM
Core Thickness 33.324 MM
Inlet Diameter 31.75 mm
Outlet Header Length 323.85 mm
Inlet Header Length 346.075 mm
Core Width 322.249 MM
Outlet Diameter 31.75 MM

Additional Information

Stock Status N
UPC 06949521747909
VMRS Code 042002001
UNSPSC 25174002

REACH COOLING 41-75 Cross References

BrandPart Number
APDI8010837
AutoZoneA75
Autokool75
CRSCUC75
CSF2097
CryoMAX75
DPI DataPoint Inc75
Federated75
GLOBAL PARTS DISTRIBUTORS75C
Keystone Auto IndustriesRAD075
Modine3586
NAPA3586, NR75X
Northern RadiatorCR75
OSC75
Performance Radiator75
Proliance431260
RadCool75
Spectra PremiumCU75
US Motor WorksUSR75
Valeo883905
Vista Pro431260
Volkswagen171121253AM

REACH COOLING 41-75 Fits Vehicles

  • Volkswagen Scirocco (1981-1983)
  • Volkswagen Jetta (1981-1984)
