REACH COOLING 41-13329 Radiator

41-13329 by REACH COOLING - Radiator
REACH COOLING
Tap to view 12 more

No Stock Available

We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.

We may have similar parts for sale. Search Alternatives >

REACH COOLING 41-13329 Part Description

Manufacturer

REACH COOLING

Product Description

Radiator

Application Summary

Buick:2012-2016 LaCrosse/ Regal; Chevrolet:2014 Impala/2013-2014 Malibu

Features & Benefits

  • Thermal expansion reduce failure rates by allowing improved core expansion and contraction.
  • Radiators are the foundation of any engine cooling system. Tasked with preventing the vehicle from overheating, the radiator is vital to keeping vehicles up and running.
  • Folded fin edges increase stability and heat disbursement properties.
  • Deep extrusion headers provide a stronger tube-to-header joint that is more resistant to the effects of vibration and thermal tube expansion.
  • Reach B-Type tubes feature central reinforcement to provide greater tolerance to pressure reducing the probability of tube failure.
  • Reach utilizes longer header tabs for increased pressure resistance, this reduces the potential for tank-to-header leaks.
  • Our included "multi-fit" attachments allow one radiator to cover multiple vehicle applications without sacrificing OE fit. This results in wider vehicle coverage with substantially less inventory.
  • Our fin edges are folded for increased stability and heat disbursement properties.
  • We design and manufacture all our radiators to meet or even exceed Original Equipment specifications. We take pride in producing the most reliable replacement parts in the market.
  • Our deep extrusion header provides a stronger tube to header joint which is more resistant to the effects of vibration and thermal tube expansion, virtually eliminating tube to header leaks.
  • Thermal expansion cuts allow for longer life and reduce failure rates by allowing improved core expansion and contraction during normal heat cycles.
  • Our B-Type tubes feature central reinforcement to provide greater tolerance to pressure. Stronger tube design means drastically reduced probability of tube failure.
  • We use longer header tabs for increased pressure resistance. This reduces the potential for tank to header leaks.
  • Our B-Type tubes feature central reinforcement to provide greater tolerance to pressure. Stronger tube design means drastically reduced probability of tube failure.
  • Our utilizes longer header tabs for increased pressure resistance, this reduces the potential for tank-to-header leaks.
  • Our B-Type tubes feature central reinforcement to provide greater tolerance to pressure reducing the probability of tube failure.

No Shipping Restriction

radiator, engine cooling, rad, car radiator, auto radiator, radiator cap

REACH COOLING 41-13329 Specifications

Product Attributes

Core Height 24.75 IN
Core Thickness 0.625 IN
Inlet Header Length 4.75 IN
Outlet Header Length 120.7 MM
Core Material Aluminum
Tank Material PA66-GF30
Inlet Diameter 0.625 IN
Radiator Cap Included Not Needed
Outlet Location Bottom Right
Transmission Oil Cooler Included No
Core Width 104.8 MM
Inlet Header Width 0.812 IN
Outlet Header Width 20.6 MM
Down Flow Or Cross Flow Type Cross Flow
Inlet Location Top Left
Outlet Diameter 0.625 IN
Core Row Quantity 1
Engine Oil Cooler Included No
Core Width 104.775 MM
Core Width 4.125 IN
Outlet Header Width 0.812 IN
Inlet Diameter 15.875 mm
Inlet Header Length 120.7 MM
Outlet Diameter 15.9 MM
Core Height 628.65 MM
Core Thickness 15.875 MM
Inlet Header Length 120.65 mm
Outlet Diameter 15.875 MM
Core Thickness 15.9 MM
Inlet Diameter 15.9 MM
Core Height 628.7 MM
Outlet Header Length 4.75 IN
Inlet Header Width 20.6 MM
Inlet Header Width 20.624 mm
Outlet Header Length 120.65 mm
Outlet Header Width 20.624 mm

Additional Information

Country of Origin (Primary) TH
UPC 06941099940300
VMRS Code 042002001
UNSPSC 25174002

REACH COOLING 41-13329 Cross References

BrandPart Number
Advance Auto Parts4113329, 813329
AutoZoneA13329, CU13329
Buick20850707
CRSCUC13329
CSF3627
Chevrolet20850707
CryoMAX13329
DPI DataPoint Inc13329
Dixin USADX13329
Factory AirRAD13329
Federated13329
GLOBAL PARTS DISTRIBUTORS13329C
General Motors20850707
Keystone Auto IndustriesINV13329, RAD13329
Kool VueP13329
Murray Heat TransferCU13329
NAPACU13329, NR13329X
Northern RadiatorCR13329
OSC13329
PACIFIC BEST INC.PR13329A
PartslinkGM3011100
Performance Radiator1765
Platinum ProINV13329
RadCool13329
Spectra PremiumCU13329
Sunbelt Radiators IncSBR13329
TYGCV37123AI
US Motor WorksUSR13329

REACH COOLING 41-13329 Fits Vehicles

  • Chevrolet Impala (2014)
  • Chevrolet Malibu (2013-2014)
  • Buick Allure (2010)
  • Buick Regal (2011-2016)
  • Buick LaCrosse (2010-2016)
