GABRIEL 85126 83000 Series FleetLine Heavy Duty Shock Absorber for Trucks, Trailers and Buses

85126 by GABRIEL - 83000 Series FleetLine Heavy Duty Shock Absorber for Trucks, Trailers and Buses
GABRIEL
Tap to view 1 more

No Stock Available

We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.

We may have similar parts for sale. Search Alternatives >

GABRIEL 85126 Part Description

Manufacturer

GABRIEL

Technical Specification
Bore 1-5/8"
Collapsed Length (in) 13.63
DustTube YES
Extended Length (in) 21.76
Installation Hardware Included Yes
Mounting Type (Upper) ES158
RecCutoff YES
Strut Mounting Type (Lower) S21

FleetLineTM Shocks – Commercial Truck and Trailer Shocks (85000 series) - Added durability makes the Fleetline™ 85000 series the standard heavy duty product for today’s low friction suspension. Designed as a direct replacement for the original equipment shock, FleetLine shock absorbers by Gabriel® provide a valving rate that compensates for initial truck suspension softening, providing performance that better matches the original ride. Built with original equipment quality components and 10 stage valving to ensure superior performance throughout the life of the shock, it also reduces wear and tear on other costly suspension and vehicle parts. And like all Gabriel shocks and struts, FleetLine shocks feature a super-finished chrome piston rod for superior corrosion resistance and a leak-proof piston seal which extends product life. Unique pressurized piston seal design reduces force-velocity variabilities and self compensates for wear. Cold formed, 360 degree arc-welded eye-ring and mounts and a 1 5/8” bore provide improved durability. A hydraulic rebound stop, where required, prevents shocks from topping out and suspensions from overextending

Features & Benefits

  • Larger 1 5/8" bore supplies improved durability and greater tensile strength for harsher operating conditions
  • Bulged design provides increased fluid capacity and cooler operation in extreme conditions
  • Forged solid steel eye rings and 360˚ arc-welded end mounts deliver tough tensile strength that reduces end mount failures
  • Best-in-class hydraulic stop provides unparalleled system durability and inhibits shocks from topping out and suspension from over-extending
  • Rugged, self-compensating piston seal for consistent damping ability and reduced fade throughout the shock life
  • Super-finished chromed piston rod ensures superior corrosion resistance, unyielding performance and extended product life
  • Custom-blended high-temperature fluid reduces friction and wear in extreme operating conditions
  • 10-stage valving equips drivers with maximum comfort and control, enhanced durability in harsh operating environments and self-cleaning functionality for longer performance
  • D.O.M (Drawn-Over-Mandrel) tubing reduces internal wear

GABRIEL 85126 Cross References

BrandPart Number
BULL DOGHD1215-0131
BULLDOG HD SHOCKSHD1215-0131
DAMON MOTOR COACH24-186537, F4-BE5-A011-HO
FLEETWOOD RV24-186537, F4-BE5-A011-HO
HOLIDAY RAMBLER24-186537, F4-BE5-A011-HO
ITASCA24-186537, F4-BE5-A011-HO
KONI8805-1003
MONACO24-186537, F4-BE5-A011-HO
MONROE557032
NATIONAL RV INC.24-186537, F4-BE5-A011-HO
WINNEBAGO24-186537, F4-BE5-A011-HO
WORKHORSE24-186537, F4-BE5-A011-HO

GABRIEL 85126 Customer Reviews

No reviews yet

Be the first to review this product!

GABRIEL 85126 Manufacturer Information

Gabriel® delivers the performance and reliability that's trusted by truck and trailer O.E. manufacturers. Gabriel's industry history started in 1907 with the invention of the original automotive shock absorber. It was soon followed by the launching of the world's first hydraulic shock absorber, then by the first adjustable shock absorber as well as the first air adjustable shock absorber. Up to this day, Gabriel is still the same pioneering and independent American company that builds the high-performance shocks and struts that are designed to fit over 96% of North American vehicles. Gabriel remains one of the country's most trusted O.E.M. and aftermarket suppliers for light- medium- and heavy-duty trucks and vehicles.
