(888) 312-8812 Login SignupMAIN FILTER MF0308119 Aftermarket Replacement Spin-On Fuel Filter with 10 Micron Rating, Cellulose, Outside-In Flow
MSRP: $56.71
$4749
Save $9.22
Limited availability at this price!
In Stock
Get it by Wednesday, Mar 4
MAIN FILTER MF0308119 Part Description
Manufacturer
Features & Benefits
- Interchange/replacement for OEM FLEETGUARD p/n HF6135
- Compatible with OEM filter in fit, form and function
- All of our elements are manufactured following ISO specifications.
- Buy hydraulic filters direct from the manufacturer
- Built using Quality Components with strict quality control.
- Main Filter MF0308119 replaces OEM HF6135 by FLEETGUARD and is compatible in fit, form and function.
- All of our elements are manufactured according to ISO specifications, including: ISO 16889, Clean DP (low and high visc) - ISO 3968, Fluid compatibility - ISO 2943, Flow fatigue resistance - ISO 3724, Dirt capacity - ISO 16889, Collapse pressure - ISO 2941
- All items marked "Replacement" or "Interchange" are not affiliated with the original manufacture where names and part numbers are for cross reference only. All trademarks are trademarks of their respective owners. Reference is made to the OEM solely to identify the compatibility of Main Filter Inc filter with the OEM filter.
- Images may be a general representations of products
Technical Specifications
| Outside Diameter Top | 5.06 |
| Outside Diameter Bottom | 5.06 |
| Thread Size | 1.5 |
| Threads | 16 UNF |
| ADBV | NO |
| Burst Pressure | 261 |
| Collapse Pressure | 72.5 |
| Flow Rate GPM | 40 GPM |
| Operating Temp Min F | -13 |
| Operating Temp Max F | 248 |
| Flow Direction | Outside-In |
| Gasket Material | Buna |
| Fluid Type | HH / HL / HM / HV |
| Beta Ratio 1 | 2/10 |
| Micron 1 | 10 |
Features & Benefits
- Interchange/replacement for OEM FLEETGUARD p/n HF6135
- Compatible with OEM filter in fit, form and function
- All of our elements are manufactured following ISO specifications.
- Buy hydraulic filters direct from the manufacturer
- Built using Quality Components with strict quality control.
- Main Filter MF0308119 replaces OEM HF6135 by FLEETGUARD and is compatible in fit, form and function.
- All of our elements are manufactured according to ISO specifications, including: ISO 16889, Clean DP (low and high visc) - ISO 3968, Fluid compatibility - ISO 2943, Flow fatigue resistance - ISO 3724, Dirt capacity - ISO 16889, Collapse pressure - ISO 2941
- All items marked "Replacement" or "Interchange" are not affiliated with the original manufacture where names and part numbers are for cross reference only. All trademarks are trademarks of their respective owners. Reference is made to the OEM solely to identify the compatibility of Main Filter Inc filter with the OEM filter.
- Images may be a general representations of products
- Buy hydraulic filters direct from the manufacturer
- Interchange/replacement for OEM FLEETGUARD p/n HF6135
- All of our elements are manufactured according to ISO specifications, including: ISO 16889, Clean DP (low and high visc) - ISO 3968, Fluid compatibility - ISO 2943, Flow fatigue resistance - ISO 3724, Dirt capacity - ISO 16889, Collapse pressure - ISO 2941
- Images may be a general representations of products
- Compatible with OEM filter in fit, form and function
- Interchange/replacement for OEM FLEETGUARD p/n HF6135
MAIN FILTER MF0308119 Specifications
Product Attributes
| Micron Rating | 10 |
| Burst Pressure | 261 |
| Bypass | No |
| Filter Area (sq. in.) | 671 |
| Flow Rater | 40 GPM |
| Handle | No |
| Height (in.) | 10.94 |
| Maximum Operating Temperature | 248 Deg Fahrenheit |
| ADBV | No |
| Thread Size | 1.5 |
| Thread Type | UNF |
| Wrap | No |
| Beta Ratio 1 | 2/10 |
| Flow Direction | Outside-In |
| Gasket Material | Buna |
| Fluid Type | HH / HL / HM / HV |
| Collapse Pressure | 72.5 |
| Outside Diameter (Top) | 5.06 in. |
| Minimum Operating Temperature | -13 Deg Fahrenheit |
| Product Media | Cellulose |
MAIN FILTER MF0308119 Cross References
| Brand | Part Number |
|---|---|
| FLEETGUARD | HF6135 |
