DORMAN TO43102 Part Description
Manufacturer
Product Description
Steering Tie Rod End
Application Summary
Volkswagen EuroVan 1996-95
Features & Benefits
- Trustworthy replacement - this steering tie rod end assembly directly replaces the original equipment on specific vehicle applications
- Durably designed - factory-sealed and precision-forged housing resists future corrosion
- Reliably engineered - built to decrease wear rate and ensure overall strength
- Trustworthy quality - backed by team of professional engineers and quality control specialists in the United States
Steering, Tie, Rod, End, Ties, Rods, Ends
DORMAN TO43102 Specifications
Product Attributes
| Length | 110 MM |
| Color | Black |
| End 1 Gender | Male |
| End 2 Gender | Female |
| Finish | Coated |
| Pre-Greased | Si |
| Grease Fitting Included | No |
| Dust Boot Included | Yes |
| Width | 35.28 MM |
| Type | Doblado |
| Mounting Hardware Included | Si |
| End 2 Thread Diameter | 16 MM |
| Height | 81.1 MM |
| Grade Type | Standard |
| Housing Material | Steel |
| Tube Diameter | 22.2 MM |
| Adjustable | Si |
| Cone Outside Diameter | 14.7 MM |
| Bearing Material | Polymer |
| End 1 Thread Direction | Clockwise (Right) |
| End 2 Thread Direction | Rotar en el sentido contrario a las agujas del reloj (izquierda) |
| Grade | Regular |
| Stud Type | Taper |
| Head Drive Type | Hex |
| End 2 Thread Pitch | 1.5 MM |
| End 1 Thread Pitch | 1.5 MM |
| Dust Boot Material | Polychloroprene |
| Tie Rod Material | Steel |
| 9093 | 2.4 MM |
| End 1 Thread Diameter | 12 MM |
| Ball Joint Included | Yes |
| Bolts Included | No |
| End 1 Attachment Type | Roscado |
| End 2 Attachment Type | Roscado |
| Material | Steel |
| Outside Diameter | 22.2 mm |
| Package Contents | 1 Tie Rod End |
| Thread Pitch | 1.5 mm; 1.5 mm |
| Tie Rod End Thread Diameter | 16 mm |
| Contenidos del paquete | 1 extremo del terminal de la direccion |
| Outside Diameter | 22.2 mm MM |
| Thread Pitch | 1.5 mm mm |
| Tie Rod End Thread Diameter | 16 mm mm |
| Diámetro de la rosca de la terminal de la dirección | 16mm MM |
| Diámetro la rosca de extremo 1 | 12 mm MM |
| Diámetro la rosca de extremo 2 | 16mm MM |
| End 1 Thread Diameter | 12 mm MM |
| End 1 Thread Pitch | 1.5 mm mm |
| End 1 Threads Per Inch | 2.4 mm MM |
| End 2 Thread Diameter | 16 mm MM |
| End 2 Thread Pitch | 1.5 mm MM |
| Espacio de la rosca del extremo 1 | 1,5mm MM |
| Espacio de la rosca del extremo 2 | 1,5mm MM |
| Espacio de la rosca por pulgada del extremo 1 | 2,4 mm MM |
| Paso de rosca | 1.5 mm MM |
Additional Information
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (Schedule B) | 8708948000 |
| Warranty Special | Limited |
| Warranty Special UOM | LF |
| UPC | 00843295058406 |
| VMRS Code | 011001031 |
| UNSPSC | 25174207 |
DORMAN TO43102 Cross References
| Brand | Part Number |
|---|---|
| Delphi | TA1641 |
| MOOG | NI |
| Mevotech Supreme | NI |
| TRW | JTE362 |
| Volkswagen | 701419812B |
DORMAN TO43102 Fits Vehicles
- Volkswagen EuroVan (1995-1996)
