DORMAN B9139 Part Description
Manufacturer
Product Description
Suspension Ball Joint
Application Summary
Mercedes-Benz 1991-73
Features & Benefits
- Direct replacement - fits and performs like the original equipment on specific vehicles
- Reliable fit - precision-engineered to match the design and dimensions of original components
- Durable construction - manufactured to strict standards using sturdy, safe materials
- Rigorously tested - thorough quality control measures ensure longevity
Suspension, Ball, Joint, Joints, Balls, Suspensions
DORMAN B9139 Specifications
Product Attributes
| Material | Acero |
| Stud Thread Diameter | 14 MM |
| Castle Nut Included | Non |
| Suspension Grade Type | Reemplazo estándar |
| Cotter Pin Hole | Non |
| Mounting Hardware Included | Non |
| Mounting Hole Quantity | 0 |
| Adjustable | Non |
| Greaseable | Non |
| Stud Type | Cónico |
| Mounting Type | A presión |
| Dust Boot Material | Élastomère |
| Attachment Type | Cono |
| Bearing Material | Polímero |
| Bolts/Studs Included | Non |
| Housing Press Fit Diameter | 45.6 mm |
| Package Contents | 1 Nut |
| Thread Pitch | 1.5 mm |
| Length | 111 MM |
| Color | Gris |
| Width | 59 MM |
| Type | Roscado |
| Height | 85.03 MM |
| Wrench Size | 12 mm MM |
| Maximum Outside Diameter | 61 MM |
| Grease Fitting Included | Non |
| Bushings Included | Non |
| Dust Boot Included | Oui |
| Ball Joint Assembly | Oui |
| Cotter Pin Included | Non |
| Washers Included | Non |
| Nuts Included | Oui |
| Stud Thread Length | 35.5 MM |
| Bushing Quantity | 0 |
| Mounting Bolts Included | Non |
| Mount Plate Included | Non |
| Tapered Stud | Oui |
| Stud Taper Per Foot | 2 IN |
| Stud Tapered End 2 Diameter | 22 MM |
| Stud Tapered End 1 Diameter | 27.2 MM |
| Stud Thread Pitch | 1.5 MM |
| Articulación de rótula instalada | Sí |
| Ball Joint Installed | Oui |
| Bushing Included | Non |
| Contenidos del paquete | 1 tuerca |
| Diámetro del acoplado a presión de la caja | 45.6 mm mm |
| Housing Press Fit Diameter | 45.6 mm MM |
| Pernos/argollas incluidos | No |
| Thread Pitch | 1.5 mm mm |
| Espacio de la rosca del espárrago | 1,5mm MM |
| Stud Thread Pitch | 1.5 mm MM |
| Stud Thread Diameter | 14 mm MM |
| Paso de rosca | 1,5mm MM |
| Nuts Included | Oui |
| Diámetro de la rosca de la argolla | 14 mm MM |
Additional Information
| Country of Origin (Primary) | IN |
| Harmonized Tariff Code (Schedule B) | 8708807000 |
| Warranty Special UOM | LF |
| Warranty Special | Limited |
| UPC | 00843295012903 |
| VMRS Code | 016001015 |
| UNSPSC | 25174203 |
DORMAN B9139 Cross References
| Brand | Part Number |
|---|---|
| ACDelco | 45D2081, 46D2081A |
| ADVANTAGE | 46D2081A |
| Beck/Arnley | 1010974, 101-0974 |
| Centric Parts | 610.35002 |
| DORMAN | 536-813 |
| Delphi | TC519 |
| MEVOTECH | MK9139 |
| MOOG | K9139 |
| MOOG Chassis Products | K9139 |
| Mcquay-Norris | FA1603 |
| Mercedes-Benz | 1163330927 |
| Mevotech Original Grade | GK9139 |
| Mevotech Supreme | MK9139 |
| QUICK STEER | K9139 |
| QuickSteer | K9139 |
| SUSPENSIA | X31BJ2230 |
| TRW | JBJ164 |
| XRF | K9139 |
| XRF Chassis | K9139 |
DORMAN B9139 Fits Vehicles
- Mercedes-Benz 350SD (1991)
- Mercedes-Benz 280S (1975-1976)
- Mercedes-Benz 500SEL (1984-1985)
- Mercedes-Benz 350SDL (1990-1991)
- Mercedes-Benz 300SEL (1988-1991)
- Mercedes-Benz 500SEC (1984-1985)
- Mercedes-Benz 380SEL (1981-1983)
- Mercedes-Benz 300SE (1988-1991)
- Mercedes-Benz 230 (1977-1978)
- Mercedes-Benz 300SDL (1986-1987)
- Mercedes-Benz 560SEL (1986-1991)
- Mercedes-Benz 450SE (1973-1976)
- Mercedes-Benz 280SE (1977-1980)
- Mercedes-Benz 380SE (1984-1985)
- Mercedes-Benz 240D (1977-1983)
- Mercedes-Benz 300SD (1979-1985)
- Mercedes-Benz 560SEC (1986-1991)
- Mercedes-Benz 420SEL (1986-1991)
- Mercedes-Benz 300CD (1978-1985)
- Mercedes-Benz 450SEL (1973-1980)
- Mercedes-Benz 380SEC (1982-1983)
- Mercedes-Benz 280CE (1978-1981)
- Mercedes-Benz 300TD (1979-1985)
- Mercedes-Benz 300D (1977-1985)
- Mercedes-Benz 280E (1977-1981)
