(888) 312-8812 Login SignupBILSTEIN 33-230405 46mm Monotube Shock Absorber
Tap to view 1 more
$15349
Limited availability at this price!
1 Day Lead Time
Get it by Thursday, Feb 26
BILSTEIN 33-230405 Part Description
Manufacturer
Product Description
B8 5125 - Shock Absorber
Application Summary
No Applications
Features & Benefits
- 46mm monotube design ensures consistent, fade-free performance in all conditions
- Patented digressive valving instantly reacts to changing surface conditions
- Vehicle specific tuning
B8 5125 Shock Absorber
BILSTEIN 33-230405 Specifications
Product Attributes
| Adjustable Damping | Non-Adjustable |
| Body Design | Smooth Body (Non-Coilover) |
| Body Diameter (id) | 46mm |
| Boot Included | Black Bellows |
| Collapsed Length (in) | 10.75 |
| Collapsed Length (in) Rounded | 11 |
| Collapsed Length (mm) | 273.0 |
| Compression @0.52m/s | 755 |
| Extended Length (in) | 16.43 |
| Extended Length (in) Rounded | 16 |
| Extended Length (mm) | 417.2 |
| Finish | Zinc Plated |
| Internal Design | Monotube |
| Lower Mount Type | Eye 5/8in |
| Mount Type | Stem-to-Eye |
| Rebound @0.52m/s | 3775 |
| RESERVOIR | No |
| Series | B8 5125 |
| Spring Seat Included | No |
| Title | Bilstein Shock Absorbers |
| Upper Mount Type | Stem |
| Segment | Light Truck |
| Parttype | Shocks / Struts |
| Prop 65 (Y/N) | Y |
| Stroke/Travel Length (IN) | 5.68 |
| Stroke/Travel Length (mm) | 144.3 |
| Piston Diameter | 46mm |
| Shaft Diameter | 14mm |
Additional Information
| Country of Origin (Primary) | MX |
| Harmonized Tariff Code (Schedule B) | 8708800050 |
| Harmonized Tariff Code (HTS) | 8708801600 |
| MSDS Sheet Number | USA SDS_Shock_Air Spring_V2_EN.pdf |
| Refurbished Part | N |
| Remanufactured Part | N |
| Warranty Time | 3 |
| Warranty Time UOM | MO |
| UPC | 00651860729282 |
BILSTEIN 33-230405 Customer Reviews
No reviews yet
Be the first to review this product!
BILSTEIN 33-230405 Manufacturer Information
About BILSTEIN Of America
Founded in 1873, BILSTEIN is a world leading manufacturer of monotube gas pressure shock absorbers. With their main headquarters located in Germany, BILSTEIN is an original equipment supplier to BMW, Jaguar, Mercedes-Benz, Porsche, GM, Chrysler, Ford, Toyota and many others. Today, BILSTEIN Aftermarket and Motorsports has grown to nearly 630 employees located in three locations around the United States and distributes more than 3,500 part numbers into the U.S. aftermarket. BILSTEIN operates within ThyssenKrupp Component Technologies Group.
