(888) 312-8812 Login SignupDELPHI TC5735 Control Arm and Ball Joint Assembly
Tap to view 13 more
$14499
Limited availability at this price!
1 Day Lead Time
Get it by Monday, Mar 16
DELPHI TC5735 Part Description
Manufacturer
Product Description
Control Arm and Ball Joint Assembly
Features & Benefits
- Delphi control arms undergo 100% crack detection and ultrasonic flaw detection to ensure materials match OE specifications
- Delphi machines the ball studs to micron tolerances to guarantee durability and smooth joint operation
- Control arms utilize robot welding for consistent performance and quality
- Anti Corrosion protection applied to each part for optimum corrosion prevention and enhanced aesthetics
DELPHI TC5735 Specifications
Product Attributes
| Item Grade | Standard Replacement |
| Position(s) | Front Right Lower |
| Pre-Greased | Yes |
| Grease Fitting Included | No |
| Bushings Included | Yes |
| Ball Joint Mounting Type | Press In |
| Ball Joint Stud Type | Threaded |
| Control Arm Construction | Stamped |
| Control Arm Material | Steel |
| Mounting Hardware Included | Yes |
| Mounting Hole Quantity | 1 |
| Adjustable | No |
| Greaseable | No |
| Control Arm Maximum Width | 3.661 IN |
| Control Arm Maximum Width | 93.00 MM |
| Control Arm Color | Black |
| Ball Joint Thread Diameter | 0.472 IN |
| Ball Joint Thread Diameter | 12.00 MM |
| Ball Joint Stud Length | 0.925 IN |
| Ball Joint Stud Length | 23.50 MM |
| Control Arm Maximum Length | 17.283 IN |
| Bushing Material | Rubber |
| Mounting Hole Diameter | 0.433 IN |
| Mounting Hole Diameter | 11.00 MM |
| Thread Direction | Clockwise (Right) |
| Bushing Color | Black |
| Finish | Painted |
| Dust Boot Included | Yes |
| Ball Joint Included | Yes |
| Grade Type | Premium |
| Boot Material | Chloroprene Rubber (CR) |
| Locking Nut Included | Yes |
| Control Arm Maximum Length | 438.99 MM |
| Thread Diameter | 12.00 MM |
| Boot Color | Black |
| Steering Type | Power |
| Bearing Material | Plastic |
| Dust Boot Material | Chloroprene Rubber (CR) |
| Thread Diameter | 0.472 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708806590 |
| Country of Origin (Primary) | TR |
| Harmonized Tariff Code (HTS) | 8708807000 |
| Warranty Special | Limited Lifetime |
| Warranty Special UOM | LF |
| UPC | 00689604314456 |
| VMRS Code | 016001001 |
| UNSPSC | 25172013 |
DELPHI TC5735 Cross References
| Brand | Part Number |
|---|---|
| Beck/Arnley | 102-6655 |
| DORMAN | CB60364, 521-754, CB60364PR, 521-660, CB60144, CB60144PR |
| Hyundai | 54501-2C602, 54501-2C607, 545012C602AS, 545012C602DS |
| MAS Industries | CB60364PR |
| MEVOTECH | CMS901019, CMS901047 |
| MOOG | RK620519 |
| MOOG Chassis Products | 102-6655 |
| N/A | CMS901020 |
DELPHI TC5735 Fits Vehicles
- Hyundai Tiburon (2005-2008)
