(888) 312-8812 Login SignupCARTER FUEL PUMPS P77046M Fuel Pump Module Assembly
No Stock Available
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
CARTER FUEL PUMPS P77046M Part Description
Manufacturer
Product Description
Fuel Pump Module Assembly
Features & Benefits
- Carter Electric Fuel Pumps and Electric Fuel Pump Assemblies are made with all new materials under rigorous quality controlled manufacturing and testing procedures.
- Quality Carter Electric Fuel Pumps and Fuel Pump Assemblies deliver optimum performance while providing long life.
- Most applications include the necessary accessories such as tank seals, patented high-gradient density strainers and wiring harnesses.
- Fuel sensor design provides resistance to corrosive fuel blends and additives.
CARTER FUEL PUMPS P77046M Specifications
Product Attributes
| Outlet Outside Diameter | 9.49 MM |
| Housing Width | 129 MM |
| Wiring Harness Length | 250.0 MM |
| Wire Gauge Measurement | 18 GU |
| Connector Color | Black |
| Terminal Type | Blade |
| Mounting Hardware Included | No |
| Height | 375 MM |
| Universal Or Specific Fit | Specific |
| Wire Quantity | 4 |
| Grade Type | Regular |
| Connector Shape | Oval |
| Gasket Or Seal Included | Yes |
| Housing Material | POM |
| Terminal Quantity | 4 |
| Top Mount Diameter | 152.0 MM |
| Lock Ring Included | No |
| Connector Gender | Female |
| Terminal Gender | Male |
| Inlet Type | Port |
| Outlet Type | Quick Connect |
| Outlet Quantity | 1 |
| Fuel Filter Included | No |
| Minimum Pressure | 60.0 PS |
| Wire Harness Included | No |
| Minimum Flow Rating | 37 GPH |
| Pump Type | Electric |
| 65000 | No Proposition 65 warning is required with this product. |
| Average Current Draw | 13.5 68 |
| Connector Quantity | 2 |
| Fuel Sending Unit Included | Yes |
| Gasket Or Seal Material | Nitrile Rubber |
| Height | 14.76 IN |
| Housing Width | 5.08 IN |
| In Tank or External | In Tank |
| Internal or External | Internal |
| Maximum Pressure | 60.92 PSI |
| Minimum Pressure | 43.51 PSI |
| Outlet Outside Diameter | 0.37 IN |
| Outlet Thread Diameter | N/A |
Additional Information
| Country of Origin (Primary) | CN |
| Country of Origin 2 | MX |
| EAR99 | |
| Harmonized Tariff Code (HTS) | 8413309030 |
| Warranty Special | Limited Lifetime Warranty |
| Warranty Special UOM | TX |
| UPC | 00889464005116 |
| VMRS Code | 044003258 |
| UNSPSC | 40151532 |
CARTER FUEL PUMPS P77046M Cross References
| Brand | Part Number |
|---|---|
| 1-800-Radiator | 2920862 |
| ACDelco | MU1860 |
| AIRTEX | E3777M |
| AUTOBEST | F2788A |
| Airtex Fuel Pumps | E3777M |
| Bosch Fuel Pumps | 69983 |
| Carquest Premium Fuel Pumps | M3520863 |
| DELPHI | FG0944 |
| Delphi Fuel Pumps | FG0944 |
| General Motors | 19206574, 19259401, 19259402, 19300009, 19300010 |
| N/A | 19206574, 19259401, 19259402, 19300009, 19300010, 2920862, 69983, A30501, C0834M, E3777M, FG0944, M3520863, MU1860, SP6625M |
| NAPA Fuel Pumps | C0834M |
| Precision Fuel | A30501 |
| Spectra Premium | SP6625M |
| TI Automotive | TU4006 |
| TYC | 150373-A |
| TruGrade | C21112920TG |
CARTER FUEL PUMPS P77046M Fits Vehicles
- GMC Sierra 1500 (2009-2013)
- Chevrolet Silverado 1500 (2009-2013)
- GMC Sierra 2500 HD (2009-2010)
- Chevrolet Silverado 2500 HD (2009-2010)
