REACH COOLING 41-1844 Radiator

41-1844 by REACH COOLING - Radiator
REACH COOLING
Tap to view 5 more

No Stock Available

We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.

We may have similar parts for sale. Search Alternatives >

REACH COOLING 41-1844 Part Description

Manufacturer

REACH COOLING

Product Description

Radiator

Application Summary

Mercedes-Benz:94-96 C220/97-98 C230/98-2000 C280/98-2003 CLK320/97-2004 SLK230

Features & Benefits

  • Folded fin edges increase stability and heat disbursement properties.
  • Deep extrusion headers provide a stronger tube-to-header joint that is more resistant to the effects of vibration and thermal tube expansion.
  • Reach B-Type tubes feature central reinforcement to provide greater tolerance to pressure reducing the probability of tube failure.
  • Reach utilizes longer header tabs for increased pressure resistance, this reduces the potential for tank-to-header leaks.
  • Thermal expansion reduce failure rates by allowing improved core expansion and contraction.
  • Radiators are the foundation of any engine cooling system. Tasked with preventing the vehicle from overheating, the radiator is vital to keeping vehicles up and running.
  • Our fin edges are folded for increased stability and heat disbursement properties.
  • Our included "multi-fit" attachments allow one radiator to cover multiple vehicle applications without sacrificing OE fit. This results in wider vehicle coverage with substantially less inventory.
  • We design and manufacture all our radiators to meet or even exceed Original Equipment specifications. We take pride in producing the most reliable replacement parts in the market.
  • Our deep extrusion header provides a stronger tube to header joint which is more resistant to the effects of vibration and thermal tube expansion, virtually eliminating tube to header leaks.
  • Thermal expansion cuts allow for longer life and reduce failure rates by allowing improved core expansion and contraction during normal heat cycles.
  • Our B-Type tubes feature central reinforcement to provide greater tolerance to pressure. Stronger tube design means drastically reduced probability of tube failure.
  • We use longer header tabs for increased pressure resistance. This reduces the potential for tank to header leaks.
  • Our B-Type tubes feature central reinforcement to provide greater tolerance to pressure. Stronger tube design means drastically reduced probability of tube failure.
  • Our B-Type tubes feature central reinforcement to provide greater tolerance to pressure reducing the probability of tube failure.
  • Our utilizes longer header tabs for increased pressure resistance, this reduces the potential for tank-to-header leaks.

No Shipping Restriction

radiator, engine cooling, rad, car radiator, auto radiator, radiator cap

REACH COOLING 41-1844 Specifications

Product Attributes

Transmission Oil Cooler Distance between Fittings 10.812 IN
Outlet Diameter 1.41 IN
Core Row Quantity 1
Engine Oil Cooler Included No
Core Height 613 MM
Core Width 428 MM
Transmission Oil Cooler Included Yes
Inlet Header Width 58.7 MM
Outlet Header Width 2.312 IN
Core Thickness 1.26 IN
Core Material Aluminum
Transmission Oil Cooler Type Concentric
Radiator Cap Included Not Needed
Trans Cooler Adapter Fittings Included (True/False) False
Outlet Location Bottom Right
Inlet Header Length 452.4 MM
Outlet Header Length 17.812 IN
Inlet Diameter 1.41 IN
Down Flow Or Cross Flow Type Cross Flow
Inlet Location Top Left
Tank Material Plastic
Core Width 428.625 MM
Outlet Header Width 58.724 mm
Core Thickness 31.75 MM
Outlet Diameter 36.499 MM
Core Height 24.13 IN
Outlet Header Length 452.424 mm
Transmission Oil Cooler Distance between Fittings 274.624 MM
Core Width 16.85 IN
Outlet Header Length 452.4 MM
Inlet Header Width 2.312 IN
Transmission Oil Cooler Distance between Fittings 274.6 MM
Outlet Header Width 58.7 MM
Inlet Diameter 36 MM
Outlet Diameter 36 MM
Inlet Header Width 58.724 mm
Core Thickness 32 MM
Inlet Diameter 36.499 mm
Core Height 612.775 MM
Inlet Header Length 452.424 mm
Inlet Header Length 17.812 IN

Additional Information

Country of Origin (Primary) TH
UPC 06949521738808
VMRS Code 042002001
UNSPSC 25174002

REACH COOLING 41-1844 Cross References

BrandPart Number
1-800-Radiator1844, 2068, 2212
APDI8011844, 8012212, 8012068
APDI RADS8011844
Advance Auto Parts432286, 432539, 811844
AutoNation19812-01771, 19812-01774
AutoZoneA1844, A2068, B2212
Autokool1844
BEHR110551, 110651, 376711191, 376711194, 376712021, 376716261, 376716271, 376711251
BesutoBES1844
CRSCRS2212, CUC2068, CUC2212
CRS AutomotiveCRS1844, CRS2068, CUC2068
CSF2336, 2922
CryoMAX2212, 0R-001844-A3CM, 0R-002068-A3CM, 0R002212A3CM, 0R001844A3CM, 0R002068A3CM, 1844, 2068
DPI DataPoint Inc2212, 1844, 2143, 2068
Dixin USADX2212, DX1844, DX2068
FVPRAD1844
Factory AirRAD2212, RAD1844, RAD2068
Federated2212, 2068
FisherCU1844, CU2068, CU2212
FronteraAM1844, AM2068, AM2212
GLOBAL PARTS DISTRIBUTORS2212C
Hella376711191, 376711194, 376712023, 376712021
Keystone Auto IndustriesRAD2212, RAD2068
KlimotoKLI1844
Kool VueP1844
Lynol Cooling SystemsLR1844
Mercedes-Benz2025002203, 2025003203, 2025003703, A 202 500 32 03, A2025002203, A2025003203, A2025003703, 2025005203, A 202 500 22 03, A 202 500 52 03, A 203 500 34 03, A2025005203, A2035003403, 202500520364
Modine3295, 3615
Murray Heat Transfer432286, 432539
NAPA3615, CU1844, 3295, NR1844A, NR2068A, NR2212A
NRF50593, 51281, 51282
Nissens62756A, 62749A, 62712A
Northern RadiatorCR1844, CR2068, CR2212, CR2143
OSC1844, 2068, 2212, USR1844, USR2212
OnixOR1844
PACIFIC BEST INC.PR1844A, PR2068A, PR2068F, PR2212A
PBIPR1844A, PR2068A
PartslinkMB3010105, MB3010101, MB3010102
Performance Radiator1844
Platinum ProRAD2068, RAD2212
Pro Parts51282
Proliance432539, 432286
RadCool1844, 2068, 2212
Reach CoolingREA411844A, REA412068A
Silla Cooling7870A
Spectra PremiumCU2212, CU1844, CU2068
Sunbelt Radiators IncSBR2068, SBR2212
Tongshi77059
UNIVERSAL AIR CONDITIONER (UAC)RA2068C
US Motor WorksUSR1844, USR2212, USR2068
Valeo732451
Vista Pro432286, 432539, 8807, 8797

REACH COOLING 41-1844 Fits Vehicles

  • Mercedes-Benz SLK230 (1997-2004)
  • Mercedes-Benz CLK320 (1998-2005)
  • Mercedes-Benz C280 (1998-2000)
  • Mercedes-Benz C230 (1997-2000)
  • Mercedes-Benz C220 (1994-1996)
