REACH COOLING 41-1689 Part Description
Manufacturer
Product Description
Radiator
Features & Benefits
- Thermal expansion cuts allow for longer life and reduce failure rates by allowing improved core expansion and contraction during normal heat cycles.
- We design and manufacture all our radiators to meet or even exceed Original Equipment specifications. We take pride in producing the most reliable replacement parts in the market.
- Folded fin edges increase stability and heat disbursement properties.
- Our included "multi-fit" attachments allow one radiator to cover multiple vehicle applications without sacrificing OE fit. This results in wider vehicle coverage with substantially less inventory.
- We use longer header tabs for increased pressure resistance. This reduces the potential for tank to header leaks.
- Deep extrusion headers provide a stronger tube-to-header joint that is more resistant to the effects of vibration and thermal tube expansion.
- Our deep extrusion header provides a stronger tube to header joint which is more resistant to the effects of vibration and thermal tube expansion, virtually eliminating tube to header leaks.
- Radiators are the foundation of any engine cooling system. Tasked with preventing the vehicle from overheating, the radiator is vital to keeping vehicles up and running.
- Thermal expansion reduce failure rates by allowing improved core expansion and contraction.
- Reach utilizes longer header tabs for increased pressure resistance, this reduces the potential for tank-to-header leaks.
- Our B-Type tubes feature central reinforcement to provide greater tolerance to pressure. Stronger tube design means drastically reduced probability of tube failure.
- Reach B-Type tubes feature central reinforcement to provide greater tolerance to pressure reducing the probability of tube failure.
- Our fin edges are folded for increased stability and heat disbursement properties.
- Our B-Type tubes feature central reinforcement to provide greater tolerance to pressure. Stronger tube design means drastically reduced probability of tube failure.
No Shipping Restriction
Radiator
REACH COOLING 41-1689 Specifications
Product Attributes
| Inlet Header Length | 473.1 MM |
| Outlet Header Length | 473.075 mm |
| Transmission Oil Cooler Distance between Fittings | 292.1 MM |
| Core Width | 438.15 MM |
| Inlet Diameter | 33.34 MM |
| Core Width | 438.15 MM |
| Engine Oil Cooler Fittings Distance Apart | 292.1 MM |
| Outlet Header Width | 60.325 mm |
| Tank Material | Plastic |
| Inlet Header Width | 2 3/8 IN |
| Inlet Header Width | 60.325 mm |
| Outlet Diameter | 39.674 MM |
| Core Height | 28.25 IN |
| Core Height | 717.55 MM |
| Outlet Header Length | 473.5 MM |
| Inlet Header Width | 60.3 MM |
| Outlet Diameter | 1 9/16 IN |
| Outlet Header Width | 2 3/8 IN |
| Transmission Oil Cooler Distance between Fittings | 292.10 MM |
| Engine Oil Cooler Fittings Distance Apart | 292.1 MM |
| Inlet Header Length | 473.075 mm |
| Inlet Header Length | 18 5/8 IN |
| Outlet Diameter | 39.7 MM |
| Radiator Cap Included | No |
| Core Height | 717.55 MM |
| Core Width | 17.25 IN |
| Transmission Oil Cooler Included | Yes |
| Outlet Header Width | 60.3 MM |
| Transmission Oil Cooler Distance between Fittings | 11.5 IN |
| Inlet Diameter | 1.312 IN |
| Core Row Quantity | 1 |
| Engine Oil Cooler Fittings Distance Apart | 11 1/2 IN |
| Inlet Diameter | 33.324 mm |
| Outlet Header Length | 18.625 IN |
| Core Material | Aluminum |
| Engine Oil Cooler Included | Yes |
REACH COOLING 41-1689 Cross References
| Brand | Part Number |
|---|---|
| Besuto | BES1689 |
| CRS Automotive | CUC622, CRS622 |
| CryoMAX | 622 |
| DPI (DataPoint Inc) | 622, 1689 |
| Delphi | RA1217 |
| General Motors | 20349, 52463934, 52465844, 52467208, 52469431, BF9393, ET9292, 3058773, 52457943, 52467210, 52469432, 52461411, EU9292, G68988, 3058774, 52459680, 52469466, G78988, 0089188, 20348, 52458333, 52463931, 20559, 20674, 52457942, 52465845, 20594, 3058768, 52457632, B59292, BO9393, ET9494 |
| Klimoto | KLI1689 |
| Modine | 2057 |
| NAPA | 2057 |
| Nissens | 60958 |
| Northern Factory Sales | 60958, 622 |
| OSC | 622 |
| Omega | 2480520, 24-80520 |
| Onix | 622 |
| PACIFIC BEST INC. | PR0622A |
| Partslink | GM3010252, GM3010251 |
| Proliance | 432057 |
| Spectra Premium | CU622 |
| Thermal Components | 46508, 4-6508 |
| Thermal Solutions Manufacturing | 432057 |
| Valeo | 731889 |
| Vista Pro | 432057 |
| Visteon | 9574 |
REACH COOLING 41-1689 Fits Vehicles
- GMC V3500 (1989-1991)
- GMC R3500 (1989-1991)
- GMC R2500 (1989)
- GMC P3500 (1996-1997)
- GMC K3500 (1988-1994)
- GMC K2500 Suburban (1992-1995)
- GMC K2500 (1988-1995)
- GMC K1500 Suburban (1992-1995)
- GMC K1500 (1988-1995)
- GMC C3500HD (1991)
- GMC C3500 (1988-1994)
- GMC C2500 Suburban (1992-1995)
- GMC C2500 (1988-1995)
- GMC C1500 Suburban (1992-1995)
- GMC C1500 (1988-1995)
- Chevrolet V3500 (1989-1991)
- Chevrolet R3500 (1989-1991)
- Chevrolet P30 (1996-1997)
- Chevrolet K3500 (1988-1994)
- Chevrolet K2500 Suburban (1992-1995)
- Chevrolet K2500 (1988-1995)
- Chevrolet K1500 Suburban (1992-1995)
- Chevrolet K1500 (1988-1995)
- Chevrolet C3500HD (1991)
- Chevrolet C3500 (1988-1994)
- Chevrolet C2500 Suburban (1992-1995)
- Chevrolet C2500 (1988-1995)
- Chevrolet C1500 Suburban (1992-1993)
- Chevrolet C1500 (1988-1995)
- Chevrolet Blazer (1994)
REACH COOLING 41-1689 Customer Reviews
No reviews yet
Be the first to review this product!
REACH COOLING 41-1689 Manufacturer Information
Founded in 1999, Reach Cooling® is a worldwide leader in the manufacture and distribution of aftermarket cooling products for light, medium, and heavy duty truck applications. Its fasting-growing division is within its medium and heavy duty truck part sector, offering more than 30 HD condensers, more than 50 HD charge air coolers, and more than 100 HD radiators. All these products are manufactured to meet the highest OE standards to fit some of the most popular US truck makes, including Peterbilt, Mack, International, Isuzu, GMC, Ford, and Freightliner. Headquartered in Miami, Florida, Reach Cooling is fully committed to providing customers with only the best products, most competitive prices, and exceptional service.
