REACH COOLING 41-147.1 Part Description
Manufacturer
Product Description
Radiator
Features & Benefits
- Our fin edges are folded for increased stability and heat disbursement properties.
- We design and manufacture all our radiators to meet or even exceed Original Equipment specifications. We take pride in producing the most reliable replacement parts in the market.
- Reach utilizes longer header tabs for increased pressure resistance, this reduces the potential for tank-to-header leaks.
- Deep extrusion headers provide a stronger tube-to-header joint that is more resistant to the effects of vibration and thermal tube expansion.
- Reach B-Type tubes feature central reinforcement to provide greater tolerance to pressure reducing the probability of tube failure.
- Folded fin edges increase stability and heat disbursement properties.
- Our B-Type tubes feature central reinforcement to provide greater tolerance to pressure. Stronger tube design means drastically reduced probability of tube failure.
- We use longer header tabs for increased pressure resistance. This reduces the potential for tank to header leaks.
- Our deep extrusion header provides a stronger tube to header joint which is more resistant to the effects of vibration and thermal tube expansion, virtually eliminating tube to header leaks.
- Our included "multi-fit" attachments allow one radiator to cover multiple vehicle applications without sacrificing OE fit. This results in wider vehicle coverage with substantially less inventory.
- Thermal expansion reduce failure rates by allowing improved core expansion and contraction.
- Radiators are the foundation of any engine cooling system. Tasked with preventing the vehicle from overheating, the radiator is vital to keeping vehicles up and running.
- Thermal expansion cuts allow for longer life and reduce failure rates by allowing improved core expansion and contraction during normal heat cycles.
- Our B-Type tubes feature central reinforcement to provide greater tolerance to pressure. Stronger tube design means drastically reduced probability of tube failure.
No Shipping Restriction
Radiator
REACH COOLING 41-147.1 Specifications
Product Attributes
| Inlet Header Length | 473.075 mm |
| Inlet Header Width | 60.325 mm |
| Outlet Header Width | 60.325 mm |
| Core Height | 20 3/4 IN |
| Inlet Header Length | 473.5 MM |
| Inlet Header Width | 60.3 MM |
| Down Flow Or Cross Flow Type | Cross Flow |
| Outlet Header Width | 2.375 IN |
| Inlet Diameter | 33.34 MM |
| Inlet Diameter | 33.324 mm |
| Outlet Diameter | 39.674 MM |
| Outlet Header Length | 473.5 MM |
| Outlet Diameter | 1 9/16 IN |
| Engine Oil Cooler Fittings Distance Apart | 292.1 MM |
| Core Material | Aluminum |
| Outlet Header Length | 473.075 mm |
| Core Width | 438.15 MM |
| Tank Material | Plastic |
| Transmission Oil Cooler Distance between Fittings | 292.10 MM |
| Engine Oil Cooler Fittings Distance Apart | 292.1 MM |
| Transmission Oil Cooler Distance between Fittings | 292.1 MM |
| Inlet Header Length | 18.625 IN |
| Outlet Header Width | 60 MM |
| Inlet Diameter | 1.312 IN |
| Outlet Diameter | 39.7 MM |
| Core Height | 527.1 MM |
| Core Width | 17.25 IN |
| Outlet Header Length | 18.625 IN |
| Core Row Quantity | 1 |
| Engine Oil Cooler Included | Yes |
| Core Height | 527.05 MM |
| Core Width | 438.15 MM |
| Transmission Oil Cooler Included | Yes |
| Inlet Header Width | 2 3/8 IN |
| Transmission Oil Cooler Distance between Fittings | 11.5 IN |
| Radiator Cap Included | No |
| Engine Oil Cooler Fittings Distance Apart | 11 1/2 IN |
REACH COOLING 41-147.1 Cross References
REACH COOLING 41-147.1 Fits Vehicles
- GMC V1500 (1987)
- GMC R2500 (1987)
- GMC R1500 (1987)
- GMC K2500 (1985)
- GMC K1500 (1985-1986)
- GMC G3500 (1985-1993)
- GMC G2500 (1985-1993)
- GMC G1500 (1985-1993)
- GMC C2500 (1985-1986)
- GMC C1500 (1985-1986)
- Chevrolet V10 (1987)
- Chevrolet R20 (1987)
- Chevrolet R10 (1987)
- Chevrolet K20 (1985)
- Chevrolet K10 (1985-1986)
- Chevrolet G30 (1985-1993)
- Chevrolet G20 (1985-1993)
- Chevrolet G10 (1985-1993)
- Chevrolet C20 (1985-1986)
- Chevrolet C10 (1985-1986)
REACH COOLING 41-147.1 Customer Reviews
No reviews yet
Be the first to review this product!
REACH COOLING 41-147.1 Manufacturer Information
Founded in 1999, Reach Cooling® is a worldwide leader in the manufacture and distribution of aftermarket cooling products for light, medium, and heavy duty truck applications. Its fasting-growing division is within its medium and heavy duty truck part sector, offering more than 30 HD condensers, more than 50 HD charge air coolers, and more than 100 HD radiators. All these products are manufactured to meet the highest OE standards to fit some of the most popular US truck makes, including Peterbilt, Mack, International, Isuzu, GMC, Ford, and Freightliner. Headquartered in Miami, Florida, Reach Cooling is fully committed to providing customers with only the best products, most competitive prices, and exceptional service.
