REACH COOLING 41-48 Part Description
Manufacturer
Product Description
Radiator
Features & Benefits
- Radiators are the foundation of any engine cooling system. Tasked with preventing the vehicle from overheating, the radiator is vital to keeping vehicles up and running.
- Our B-Type tubes feature central reinforcement to provide greater tolerance to pressure. Stronger tube design means drastically reduced probability of tube failure.
- Reach utilizes longer header tabs for increased pressure resistance, this reduces the potential for tank-to-header leaks.
- Deep extrusion headers provide a stronger tube-to-header joint that is more resistant to the effects of vibration and thermal tube expansion.
- Reach B-Type tubes feature central reinforcement to provide greater tolerance to pressure reducing the probability of tube failure.
- Our fin edges are folded for increased stability and heat disbursement properties.
- We design and manufacture all our radiators to meet or even exceed Original Equipment specifications. We take pride in producing the most reliable replacement parts in the market.
- Thermal expansion cuts allow for longer life and reduce failure rates by allowing improved core expansion and contraction during normal heat cycles.
- Folded fin edges increase stability and heat disbursement properties.
- Our deep extrusion header provides a stronger tube to header joint which is more resistant to the effects of vibration and thermal tube expansion, virtually eliminating tube to header leaks.
- Our included "multi-fit" attachments allow one radiator to cover multiple vehicle applications without sacrificing OE fit. This results in wider vehicle coverage with substantially less inventory.
- Thermal expansion reduce failure rates by allowing improved core expansion and contraction.
- We use longer header tabs for increased pressure resistance. This reduces the potential for tank to header leaks.
- Our B-Type tubes feature central reinforcement to provide greater tolerance to pressure. Stronger tube design means drastically reduced probability of tube failure.
No Shipping Restriction
Radiator
REACH COOLING 41-48 Specifications
Product Attributes
| Core Height | 401.6 MM |
| Inlet Header Length | 28 1/8 IN |
| Tank Material | Plastic |
| Outlet Header Width | 1.937 IN |
| Outlet Header Width | 49 MM |
| Core Width | 687.374 MM |
| Outlet Diameter | 34.925 MM |
| Outlet Header Length | 714.375 mm |
| Core Width | 687.39 MM |
| Transmission Oil Cooler Distance between Fittings | 11 13/16 IN |
| Core Height | 401.624 MM |
| Inlet Header Width | 49.2 MM |
| Transmission Oil Cooler Distance between Fittings | 300 MM |
| Outlet Diameter | 1.375 IN |
| Core Row Quantity | 1 |
| Core Thickness | 15.875 MM |
| Transmission Oil Cooler Distance between Fittings | 300.024 MM |
| Core Width | 27.062 IN |
| Inlet Header Length | 714.4 MM |
| Inlet Diameter | 34.9 MM |
| Inlet Diameter | 34.925 mm |
| Core Thickness | 15.9 MM |
| Outlet Header Length | 28 1/8 IN |
| Engine Oil Cooler Included | No |
| Inlet Header Length | 714.375 mm |
| Core Thickness | 5/8 IN |
| Transmission Oil Cooler Included | Yes |
| Radiator Cap Included | No |
| Inlet Header Width | 49.199 mm |
| Core Height | 15 13/16 IN |
| Core Material | Aluminum |
| Inlet Header Width | 1 15/16 IN |
| Outlet Diameter | 34.93 MM |
| Outlet Header Width | 49.199 mm |
| Outlet Header Length | 714.4 MM |
| Inlet Diameter | 1 3/8 IN |
Additional Information
| Country of Origin (Primary) | CN |
| UPC | 06949521715960 |
| VMRS Code | 042002001 |
| UNSPSC | 25174002 |
REACH COOLING 41-48 Cross References
| Brand | Part Number |
|---|---|
| 1-800-Radiator | 48, 1242 |
| APDI | 8011242 |
| Autokool | 48 |
| Besuto | BES48 |
| CSF | 2464, 970, 920, 2463 |
| CryoMAX | 0AYL2528, 0AYL2527, 0AYL2558 |
| DPI (DataPoint Inc) | 1242, 1941, 1185, 1150, 48 |
| Datsun/Nissan | 2141085, 2150000, 2141040P00, 2146030P00, 2146085E01, 2141085E01, 21460850, 2140000, 21400000, 1R220892208, 2141030P00, 2141030P10, 2141085E00, 2146085E00, 2150085E00, 21460960, 2146085, 2146096E01, 21500000, 2150085, 21410850, 2146030P10 |
| GLOBAL PARTS DISTRIBUTORS | 48C |
| Keystone Auto Industries | RAD048 |
| Klimoto | KLI48 |
| Koyo | A1150, A1242 |
| Modine | 2208 |
| NAPA | 2208 |
| OSC | 1150, 48, 1185, 1242 |
| Onix | OR1242 |
| Parts Plus | CU1242 |
| Partslink | NI3010144, NI3010146 |
| Performance Radiator | 48CBR, 48 |
| Proliance | 432208 |
| Silla Cooling | 7160, 7160A |
| Spectra Premium | CU1242 |
| TYC | 1242 |
| Vista Pro | 9808, 432208 |
REACH COOLING 41-48 Fits Vehicles
- Nissan Maxima (1989-1994)
- Nissan 300ZX (1989-1996)
REACH COOLING 41-48 Customer Reviews
No reviews yet
Be the first to review this product!
REACH COOLING 41-48 Manufacturer Information
Founded in 1999, Reach Cooling® is a worldwide leader in the manufacture and distribution of aftermarket cooling products for light, medium, and heavy duty truck applications. Its fasting-growing division is within its medium and heavy duty truck part sector, offering more than 30 HD condensers, more than 50 HD charge air coolers, and more than 100 HD radiators. All these products are manufactured to meet the highest OE standards to fit some of the most popular US truck makes, including Peterbilt, Mack, International, Isuzu, GMC, Ford, and Freightliner. Headquartered in Miami, Florida, Reach Cooling is fully committed to providing customers with only the best products, most competitive prices, and exceptional service.
