RANCHO RS55830 Part Description
Manufacturer
Product Description
Suspension Strut
Features & Benefits
- IMPROVED HANDLING AND PERFORMANCE -- Cross Tuned technology featuring exclusive rebound valving system and advanced compression phase improves overall handling and performance on and off road
- MINIMIZES ROUGH RIDE -- Exclusive Progressive Engagement Valving is custom-tuned for each vehicle to help reduce initial impacts at low speeds and minimizes a rough ride
- STRONG AND DURABLE -- Features a nitro-carburized piston rod to resist scuffs & corrosion, double-welded loops at stress areas, application-specific sintered iron piston for enhanced structural integrity and polyvinyl protective boot
- HANDLES EXTREME TEMPERATURE CHANGES -- Large twin-tube body filled with all-weather fluid allows for cooler operation, increased vehicle control and ability to withstand internal temperatures of -40 to 248degF
- HANDLES EXTREME TEMPERATURE CHANGES -- Large twin-tube body filled with all-weather fluid allows for cooler operation, increased vehicle control and ability to withstand internal temperatures of -40 to 248°F
- SMOOTH PERFORMANCE -- Polyurethane rebound bumper and rubber bushings help absorb ride harshness while the fluon-banded piston enhances responsiveness to changing road conditions for an overall smoother ride
- REDUCES FADE -- Nitrogen gas pressurized to 60 PSI to minimize air-to-oil mixture to reduce damping performance fade and foaming
- MAINTAINS VEHICLE CONTROL -- Compression Control Valve is custom-tuned for each vehicle to regulate fluid transfer to absorb impacts without disc flutter and help maintain shock motion control
- BUILT TO LAST -- Low-friction, self-lubricating seal retains gas and oil for quicker rebound and smoother compression while the application-specific piston delivers heightened control of shock motion due to the expanded piston area
- BUY WITH CONFIDENCE -- Comes with Rancho's Limited Lifetime Warranty
- BUY WITH CONFIDENCE -- Comes with Rancho’s Limited Lifetime Warranty
RANCHO RS55830 Specifications
Product Attributes
| Body Type | SS7 |
| Compressed Length | 13.57 IN |
| Travel Length | 3.27 in |
| Grade Type | Performance |
| Extended Length | 16.84 in |
| Upper Mount Type | XP16 |
| Gas Charged | Yes |
| Body Length | 13.07 IN |
| Adjustable Damping | No |
| Dust Shield Included | No |
| Includes Bump Stop | No |
| Internal Rebound Bumper | Yes |
| Finish | Painted |
| Hydraulic Lockout | No |
| Lower Mount Type | Loop Bushing Mount - 5/8" Bushing ID X 1.5/16" Bushing OAL |
| Parts Pack(s) | P01788,P01415 |
| Upper Mount Code | XP16 |
| Compressed Length | 344.7 MM |
| Extended Length | 427.7 MM |
| Travel Length | 83.1 MM |
| Body Length | 332 MM |
| Lower Mount Type | Loop (Eyelet) Bushing |
Additional Information
| Country of Origin (Primary) | CN |
| Canadian Harmonizing Tariff Code | 8708803000 |
| Harmonized Tariff Code (Schedule B) | 8708801600 |
| Harmonized Tariff Code (HTS) | 8708801600 |
| MSDS Sheet Number | 01170 |
| UPC | 00039703006149 |
| VMRS Code | 016020000 |
| UNSPSC | 25172007 |
RANCHO RS55830 Cross References
| Brand | Part Number |
|---|---|
| BILSTEIN | 24-238281, 24-337113 |
| Bilstein | 24238281 |
| FCS | 345815 |
| GABRIEL | G51949 |
| Gabriel | G51870 |
| General Motors | 22891309, 22891310, 22891324, 23106628, 23106629, 23106630, 23124590, 23124591, 23124592, 23124593, 23124594, 23124595, 23124596, 23124598, 23130121, 23130122, 23148687, 23156080, 23156081, 23156082, 23172263, 23179308, 23183864, 23183876, 23183880, 23183892, 23268093, 23275423, 23276075, 23338789, 23338792, 23338796, 23338800, 23338809, 23338814, 23338824, 23338831, 23338839, 23338844, 23338854, 23338859, 23338863, 23338867, 23338871, 23338879, 23425607, 23425611, 23452959, 84043171, 84043175, 84043185, 84043190, 84043195, 84081998, 84082002, 84082006, 84082021, 84082031, 84082035 |
| KYB | 5510018 |
| MONROE | 39112 |
| Monroe Shocks & Struts | 39112 |
| NAPA Shocks | 39112 |
| Sensen | 32140231 |
RANCHO RS55830 Fits Vehicles
- Chevrolet Silverado 1500 LD (2019)
- GMC Sierra 1500 Limited (2019)
- GMC Yukon XL (2015-2020)
- Chevrolet Suburban (2015-2020)
- GMC Yukon (2015-2020)
- Chevrolet Tahoe (2015-2020)
- GMC Sierra 1500 (2014-2018)
- Chevrolet Silverado 1500 (2014-2018)
