RANCHO RS55120 Part Description
Manufacturer
Product Description
RS5000X Suspension Shock Absorber
Features & Benefits
- IMPROVED HANDLING AND PERFORMANCE -- Cross Tuned technology featuring exclusive rebound valving system and advanced compression phase improves overall handling and performance on and off road
- MINIMIZES ROUGH RIDE -- Exclusive Progressive Engagement Valving is custom-tuned for each vehicle to help reduce initial impacts at low speeds and minimizes a rough ride
- STRONG AND DURABLE -- Features a 16mm nitro-carburized piston rod to resist scuffs & corrosion, double-welded loops at stress areas, 35mm sintered iron piston for enhanced structural integrity and polyvinyl protective boot
- HANDLES EXTREME TEMPERATURE CHANGES -- Large twin-tube body filled with all-weather fluid allows for cooler operation, increased vehicle control and ability to withstand internal temperatures of -40 to 248degF
- HANDLES EXTREME TEMPERATURE CHANGES -- Large twin-tube body filled with all-weather fluid allows for cooler operation, increased vehicle control and ability to withstand internal temperatures of -40 to 248°F
- SMOOTH PERFORMANCE -- Polyurethane rebound bumper and rubber bushings help absorb ride harshness while the fluon-banded piston enhances responsiveness to changing road conditions for an overall smoother ride
- REDUCES FADE -- Nitrogen gas pressurized to 150 PSI to minimize air-to-oil mixture to reduce damping performance fade and foaming
- MAINTAINS VEHICLE CONTROL -- Compression Control Valve is custom-tuned for each vehicle to regulate fluid transfer to absorb impacts without disc flutter and help maintain shock motion control
- BUILT TO LAST -- Low-friction, self-lubricating seal retains gas and oil for quicker rebound and smoother compression while the application-specific piston delivers heightened control of shock motion due to the expanded piston area
- BUY WITH CONFIDENCE -- Comes with Rancho's Limited Lifetime Warranty
- BUY WITH CONFIDENCE -- Comes with Rancho’s Limited Lifetime Warranty
RANCHO RS55120 Specifications
Product Attributes
| Compressed Length | 9.86 IN |
| Travel Length | 4.28 in |
| Finish | Painted |
| Grade Type | Performance |
| Extended Length | 14.14 in |
| Gas Charged | Yes |
| Adjustable Damping | No |
| Dust Shield Included | Yes |
| Includes Bump Stop | No |
| Upper Mount Code | L1 |
| Lower Mount Code | LS36 |
| Hydraulic Lockout | No |
| Shock Absorber Bore Size | 35 MM |
| Internal Rebound Bumper | Yes |
| Body Diameter | 2.251 |
| Internal Construction Type | Dual Tube |
| Lower Mount Type | Loop Bushing and Sleeve Mount - 1/2" Sleeve ID X 1.5/16" Sleeve OAL |
| Part Description | Shock Absorber |
| Parts Pack(s) | P00915, P00916 |
| Upper Mount Type | Loop Bushing Mount - 5/8" Bushing ID X 1.5/16" Bushing OAL |
| Compressed Length | 250.4 MM |
| Extended Length | 359.2 MM |
| Travel Length | 108.7 MM |
| Shock Stroke | 4.28 IN |
| Shock Stroke | 108.7 MM |
| Lower Mount Code | LS36 |
| Upper Mount Code | L1 |
| Shock Absorber Rod End Measuring Point | Center of Loop |
| Shock Absorber Body End Measuring Point | Center of Loop |
| Mounting Hardware Included | Yes |
| Body Diameter | 2.251 IN |
| Body Diameter | 57.2 MM |
| Cylinder Outside Diameter | 2.251 IN |
| Cylinder Outside Diameter | 57.2 MM |
| Body Material | Steel |
| Cylinder Material | Steel |
| Body Color | White |
| Cylinder Color | White |
| Color | White |
| Cylinder Finish | Painted |
| Boot Included | Yes |
| Dust Shield Diameter | 2.99 IN |
| Dust Shield Diameter | 75.946 MM |
| Dust Shield Material | Rubber |
| Dust Shield Color | Red |
| Rod Diameter | 0.622 IN |
| Rod Diameter | 15.8 MM |
| Shaft Material | Nitro-Carburized Steel |
| Shock Absorber Bore Size | 1.3779527559055118 IN |
| Internal Rebound Spring | No |
| Type | Telescopic |
| Active or Passive Suspension | Passive |
| Adjustable Compression | No |
| Adjustable Rebound | No |
| Valving Type | Progressive |
| Self-Leveling | No |
| Adjustable Ride Height | No |
| Maximum Ride Height Lowering Distance | 0 IN |
| Maximum Ride Height Raising Distance | 0 IN |
| Air Adjustable | No |
| Air Ride Suspension | No |
| Bladder(s) Included | No |
| Bladder Sleeve(s) Included | No |
| Bladder Heavy Duty Crimping Rings Included | No |
| New Or Remanufactured | New |
| Coil Over Springs Included | No |
| Bearing Plate Included | No |
| Spring Included | No |
| Coil Spring Insulator(s) Included | No |
| Spring Isolators Included | No |
| Spring Seat Included | No |
| Remote Reservoir | No |
| Strut Mount Insulator(s) Included | No |
| Adjustable Damping | No |
| Internal Construction Type | Twin Tube |
| Lower Mount Type | Loop (Eyelet) Bushing and Sleeve |
| Upper Mount Type | Loop (Eyelet) Bushing |
Additional Information
| Country of Origin (Primary) | US |
| Canadian Harmonizing Tariff Code | 8708803000 |
| Harmonized Tariff Code (Schedule B) | 8708801600 |
| Harmonized Tariff Code (HTS) | 8708801600 |
| MSDS Sheet Number | 01164 |
| UPC | 00039703010375 |
| VMRS Code | 016008003 |
| UNSPSC | 25172011 |
RANCHO RS55120 Cross References
RANCHO RS55120 Fits Vehicles
- GMC 2500 (1966)
- GMC Suburban (1963-1966)
- GMC G35/G3500 Van (1970-1974)
- GMC G25/G2500 Van (1970-1974)
- GMC G15/G1500 Van (1970-1974)
- GMC C35/C3500 Pickup (1967-1974)
- GMC C25/C2500 Suburban (1968-1974)
- GMC C25/C2500 Pickup (1967-1974)
- GMC C15/C1500 Suburban (1968-1974)
- GMC C15/C1500 Pickup (1967-1974)
- GMC 2500 Series (1963-1965)
- Chevrolet G30 Van (1970-1974)
- Chevrolet G20 Van (1970-1974)
- Chevrolet G10 Van (1970-1974)
- Chevrolet C30 Pickup (1963-1974)
- Chevrolet C20 Pickup (1963-1974)
- Chevrolet C10 Pickup (1963-1974)
- Chevrolet Blazer (1969-1974)
- GMC R3500 (1987-1991)
- GMC R2500 Suburban (1987-1991)
- GMC R2500 (1987-1989)
- GMC R1500 Suburban (1987-1991)
- GMC R1500 (1987)
- GMC Jimmy (1970-1982)
- GMC G3500 (1979-1995)
- GMC G35 (1975-1978)
- GMC G2500 (1979-1995)
- GMC G25 (1975-1978)
- GMC G1500 (1979-1995)
- GMC G15 (1975-1978)
- GMC C3500 (1979-1986)
- GMC C35 (1975-1978)
- GMC C2500 Suburban (1979-1986)
- GMC C25 Suburban (1975-1978)
- GMC C2500 (1979-1986)
- GMC C25 (1975-1978)
- GMC C1500 Suburban (1979-1986)
- GMC C15 Suburban (1975-1978)
- GMC C1500 (1979-1986)
- GMC C15 (1975-1978)
- Chevrolet R3500 (1989-1991)
- Chevrolet R30 (1987-1988)
- Chevrolet R2500 Suburban (1989-1991)
- Chevrolet R2500 (1989)
- Chevrolet R20 Suburban (1987-1988)
- Chevrolet R20 (1987-1988)
- Chevrolet R1500 Suburban (1989-1991)
- Chevrolet R10 Suburban (1987-1988)
- Chevrolet R10 (1987)
- Chevrolet G30 (1975-1995)
- Chevrolet G20 (1975-1995)
- Chevrolet G10 (1975-1995)
- Chevrolet C30 (1975-1986)
- Chevrolet C20 Suburban (1967-1986)
- Chevrolet C20 (1975-1986)
- Chevrolet C10 Suburban (1967-1986)
- Chevrolet C10 (1975-1986)
- Chevrolet K5 Blazer (1975-1982)
- Jeep Wagoneer (1975)
